3.4 Menu Items Cont'd
Menu or Key
Function
Blade Length
To adjust the length of the blade
Adjust
Note:
1.
2.
pressing ENTER.
3.
perform blade holder and blade length tests.
4.
screen will show you to what degree (the unit of the value following
"CW" or "CCW" is "circle") and in which direction [CW (clock-
wise) or CCW (counterclockwise)] you should turn the adjustment
knob. I.E. "Turn CW 0.5" means you should turn the knob clock-
wise one half turn.
5.
is perfect and no more adjustment needs to be made. You may start
cutting at this point.
To clear buffer memory.
Set Smoothing
To enable smooth-cutting function.
Cut
Over Cut
To generate an overcut to facilitate weeding.
Set Tangential
To enable the emulated tangential-cutting mode for thicker media
Mode
types and small letter cuts.
Note: If the Offset value is set at 0.000 mm, "Set Tangential Mode"
will automatically be disabled.
Panel Setup
Accept setup command:
To accept commands of the Force, Speed, Cutting Quality, and
Offset only from software.
Control panel only:
To accept commands of the Force, Speed, Cutting Quality, and
Offset only from the control panel of the cutter.
Restore Default
To return all parameters of the menu items to factory-default
settings.
Keep your blade length as 0 before you start adjusting.
Test the blade holder first and then test the blade length by
Keep the blade holder at the same position when you
When blade holder and blade length tests are finished, the
The value on the screen will be 0.0 when the blade length
[ DATA CLEAR ]
[ TOOL SELECT ]
Continued Next Page...
2614 Texoma Drive Denison, TX 75020 • 980 Contract St. Suite 110 Lexington, KY
Phone: 903-462-7700 or toll free 800-899-5655 • Fax: 800-966-6834
27
User Manual
Setting
0.00mm-5.00mm
0.00mm-1.00mm
0.05mm/per step
Default
0.00mm
Enable
0.00mm
Disable
