User Manual
4. Insert the blade holder into tool carriage. Please note the outward ring of the holder must put
into the groove of carriage firmly (Figure 2-9) and lock the grip. (Figure 2-10)
Figure 2-10
Figure 2-9
5. Reverse steps mentioned above to remove the blade holder.
6. Press the push-pin to remove the blade from the blade holder when replacing blade. (Figure 2-11)
Figure 2-11
2614 Texoma Drive Denison, TX 75020 • 980 Contract St. Suite 110 Lexington, KY
Phone: 903-462-7700 or toll free 800-899-5655 • Fax: 800-966-6834
13
