2.3 Blade Installation
Caution!
• Do not touch the tip of the blade with your fingers!
Notice!
The blade is a consumable item, which will affect the cutting quality significantly. Please replace with
a new blade when having the following situations:
1. The tip of blade is broken.
2. The cutting traces are not as good as they were.
3. Uncut area remains the same even the blade force has been raised significantly
Figure 2-5 is the picture of the blade holder. Insert a blade into the bottom of the blade holder.
Pushing the pin on the top of blade holder can remove the blade. Be sure to keep your fingers away
from the blade tip.
Outer Ring
Figure 2-5
2614 Texoma Drive Denison, TX 75020 • 980 Contract St. Suite 110 Lexington, KY
Phone: 903-462-7700 or toll free 800-899-5655 • Fax: 800-966-6834
11
User Manual
Pin
Blade Depth Adjustment
Knob
