Waterproof/Dustproof Function - Docomo Style series F-10C Instruction Manual

Waterproof/Dustproof function

F-10C provides waterproofness of IPX5
and dustproofness of IP5X
the external connection jack cap and installing
the back cover in a locked state.
*1 IPX5 means that a phone keeps functioning after
applying a jet flow of 12.5 L/min. from every
direction from a distance of approximately 3 m for at
least 3 minutes using water nozzle in 6.3 mm inner
diameter.
*2 For F-10C, IPX8 means that a phone keeps
functioning after F-10C is slowly submerged to
depth of 1.5m in static tap water at room
temperature, left there for 30 minutes and then taken
out, and the mobile phone keeps shooting still
images or moving pictures in approximately 30
minutes in static tap water at room temperature.
*3 IP5X means a protection degree that a phone keeps
functioning and safety after it is placed in a device
with dust in diameter 75
agitated and then taken out.
✜
What you can do with waterproofness/
dustproofness of F-10C
You can talk or watch 1Seg programs without
using an umbrella in the rain (for rainfall of 20
mm or less per hour).
- When your hands or the FOMA terminal are
wet, avoid installing/removing the back cover
or opening/closing the external connection
jack cap.
20
*1 *2
, IPX8
*3
with firmly closing
or less for 8 hours,
You can also shoot still images and moving
pictures in the pool depth of 1.5 m.
- Do not perform other operations underwater
than shooting still images and moving
pictures.
- If you put the terminal in water of swimming
pool, be sure to have it within 30 minutes.
- If FOMA terminal gets wet with water from the
swimming pool, wash it in specified procedure
( P22).
You can use FOMA terminal in a bathroom.
- Do not put the terminal in the bathtub. Do not
use the terminal in hot water. May cause
malfunction.
- Never put FOMA terminal in hot spring water
or water containing soap, detergent or bath
powder.
To ensure waterproofness/
dustproofness
To avoid water/dust ingress, be sure to observe
the following points.
Do not throw any liquid other than room-
temperature tap water on FOMA terminal, or
soak it in such liquid.
When using the external connection jack, pull
the cap up with your finger by the groove as
shown in the illustration.
Groove
