Communication protocol result code
No. Text display
1 PPPoverUD
3 AV64K
5 PACKET
Display example of result code
When ATX0 is set
Regardless of the settings of AT V command, only "CONNECT" is displayed upon completion of
connection.
Text display example : ATD
CONNECT
Number display example : ATD
When ATX1 is set
When ATX1, AT V0 (default) is set
Upon completion of connection, the result code is displayed in the following format : "CONNECT <speed
between FOMA terminal - PC>".
Text display example : ATD
Number display example : ATD
When ATX1, AT V1 is set
The code is displayed upon completion of connection in the following format.
"CONNECT<speed between FOMA terminal - PC><Communication protocol><dialup connection (APN)>/
<upstream maximum speed (between FOMA terminal
speed (between FOMA terminal
Text display example : ATD
CONNECT 460800 PACKET mopera.ne.jp/5760/7232
(Indicates the terminal is connected to mopera.ne.jp providing a maximum upload speed of 5,760kbps
and a maximum download speed of 7,232kbps.)
Number display example : ATD
*1 When ATX1 and AT V1 are set at the same time, it is likely that dialup connection will fail. It is recommended that
only AT V0 be used.
*2 When AT V1 is set, <dialup connection (APN)> and the following are displayed only when packet is used for
connection.
Connect via 64K data communication (BC=UDI, +CBST=116,1,0)
Connect via 64K videophone
Connect via packet communication
99 1#
99 1#
1
99 1#
CONNECT 460800
99 1#
1 21
*1
radio base station)>"
99 1#
99 1#
1 21 5
Meaning
radio base station)>/<downstream maximum
*2
37
