W.M.D. POWER CONNECTOR
The W.M.D. PWR connector is a 2-pin 1B LEMO power connector to supply power to the W.M.D. from your
camera or other power modules.
1
2
PIN
1
2
COPYRIGHT © 2014 RED.COM, INC
2-PIN 1B LEMO POWER CONNECTOR
SIGNAL
GND
+12 V
W.M.D. 2-Pin 1B Power connector
