R E D 3 - A X I S S Y S T E M O P E R AT I O N G U I D E

CONFIGURE LENS CONTROL MOTORS

The W.M.D. features a number of adjustments in the Focus, Iris, and Zoom menu topics to fine-tune specific
motor/lens combinations. After initializing the system, you may need to adjust the following settings:
 Torque
 Direction
 Type/Model
 Backlash
 Endstop
NOTE: For more information, go to

METADATA AND LENS PROFILES

The microSD slot on the W.M.D. is used to update firmware, as well as save and share modified lens profiles
that allow you to view real-time metadata on the W.M.D. This guide offers information on the following topics:
 Select a Lens Profile
 Modify a Lens Profile
 Clear the Active Lens Profile
 View Lens Metadata
 Export Lens Profiles
 Import Lens Profiles
NOTE: For more information, go to

LENS LIMITS AND LENS LOCKS

The T.H.C. features several convenient and easy-to-use features for precision wireless control. This guide offers
information on the following topics:
 Set a Lens Limit
 Remove a Lens Limit
 Set a Lens Lock
 Remove a Lens Lock
NOTE: For more information, go to the chapter
COPYRIGHT © 2014 RED.COM, INC
"Configure Focus, Iris, and Zoom Motors" on page
"W.M.D. Lens Profiles" on page
"Tactical Hand Controller (T.H.C.)" on page
24.
28.
32.
955-0044, REV-D | 15
