- Page 2 • Batteries are compact, lightweight, and support high continuous load use. • Sophisticated electronics provide safety protection and optimal performance. • RED EVF, RED LCD, RED PRO LCD display and 5 step LED indicators on the RED BRICK accurately monitor remaining capacity.
- Page 3 As a responsible manufacturer, RED DIGITAL CINEMA® is confident in the quality and workmanship of this RED BRICK battery. We guarantee it to be free from defects in material or workmanship for 90 days from date of delivery or 400 charge cycles (whichever occurs first).
- Page 4 • If you find discoloration, a bad odor due to leakage, overheating and/or other irregularities when using the battery for the first time contact your RED™ service representative.
- Page 5 possibly leading to chemical leakage, overheating, smoke emission, bursting and/or ignition. • Do not use or leave the battery near a heat source such as a fire or a heater (> 80°C). If the resin separators should become damaged due to overheating, short- circuiting may occur inside the battery, possibly leading to chemical leakage, over- heating, smoke emission, bursting and/or ignition of the battery.
- Page 6 CONNECTING & CHARGING BATTERY BATTERY CONNECTING BATTERY TO RED ONE CAMERA Battery can be connected to the RED ONE camera through the RED BATTERY PLATE, RED QUICKPLATE or RED CRADLE. CHARGING USING RED CHARGER 1. Plug AC power cord into charger AC input and power source. 2. Turn the charger power switch ON.
- Page 7 RED BRICK Discharge Voltage VS. State of Charge at 60W and 80W Load State of Charge (%) RED BRICK Discharge Voltage VS. Time at 60W and 80W Load Time (Min) Nominal Maximum Nominal Maximum Nominal Operating Energy Weight Dimensions Voltage...
- Page 8 OPERATION GUIDE, which is provided solely for the user’s information. While thought to be accurate, the information in this document is provided strictly “as is” and RED will not be held responsible for issues arising from typographical errors or user’s interpretation of the language used herein that is different from that intended by RED™.
