RED Motion mount TI PL Operation Manual

Hide thumbs Also See for Motion mount TI PL:
Table of Contents

Advertisement

Quick Links

Download this manual
RED MOTION MOUNT
O P E R AT I O N G U I D E
M O T I O N M O U N T T I P L
|
M O T I O N M O U N T T I C A N O N
R E D . C O M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Motion mount TI PL and is the answer not in the manual?

Questions and answers

Related Manuals for RED Motion mount TI PL

Summary of Contents for RED Motion mount TI PL

  • Page 1 RED MOTION MOUNT O P E R AT I O N G U I D E M O T I O N M O U N T T I P L M O T I O N M O U N T T I C A N O N...

  • Page 2: Table Of Contents

    Camera Does Not Recognize the MOTION MOUNT 27 Irregular Out-of-Focus Bokeh Effects and Flare Double Exposures in Captured Footage Appendix A: Technical Specifications RED MOTION MOUNT Ti PL RED MOTION MOUNT Ti Canon Neutral Density and Shutter Angles Maximum Frame Rates...

  • Page 3: Disclaimer

    While thought to be accurate, the information in this document is device, pursuant to part 15 of the FCC Rules. provided strictly “as is” and RED will not be held responsible for is- These limits are designed to provide reason- sues arising from typographical errors or user’s interpretation of the...
  • Page 4 R E D M O T I O N M O U N T O P E R AT I O N G U I D E AUSTRALIA AND NEW ZEALAND STATEMENTS WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE) RED declares that the radio equipment described in this document The Waste Electrical and Electronic Equip- comply with the following international standards.

  • Page 5: Safety Instructions

    WARNING: Danger of explosion if an incor- duce heat. Store in a protected, level and ventilated place. rect battery is charged with the RED Char- Avoid exposure to temperature extremes, damp, severe vibra- ger or is used to power the camera and tion, strong magnetic fields, direct sunlight or local heat sourc- accessories.

  • Page 6: Chapter 1: Motion Mount Introduction

    The global shutter ensures uniform exposure throughout your image, regardless of strobes or motion. For more information about global shutters, see the Global & Rolling Shutters article available at www.red.com/ learn/red-101/global-rolling-shutter. COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-K |...

  • Page 7: Motion Mount Components

     REDCINE-X PRO Build 20.0.0 or later ® NOTE: RED MOTION MOUNT Ti PL and RED MOTION MOUNT Ti Canon use identical filter and shutter mechanisms. The only differences between the mounts are the mechanical locking systems and compatible lenses.

  • Page 8: Chapter 2: Motion Mount Installation

    R E D M O T I O N M O U N T O P E R AT I O N G U I D E MOTION MOUNT INSTALLATION The RED MOTION MOUNT is installed in the same way as other RED lens mounts. Installation and removal ® steps provided in this section apply to the following lens mounts: ITEM...

  • Page 9: Lens Mount Alignment

    When installing the MOTION MOUNT, ensure that the lens mount is properly aligned. The forward-facing contact pins differ between the two (2) mounts. RED MOTION MOUNT Ti PL contacts pins are located on the top of the mount, while RED MOTION MOUNT Ti Canon contact pins are located on the bottom of the mount.

  • Page 10: Install The Motion Mount

    MOTION MOUNT. Ensure that they are free of any contamination. 2. Align the MOTION MOUNT on the front of the camera. The camera connection pins must align with the MOTION MOUNT pins. Align MOTION MOUNT pins COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-K |...
  • Page 11 NOTE: For more information and troubleshooting, go to “Camera Does Not Recognize the MOTION MOUNT” on page NOTE: If you need to replace any screws, please contact your Bomb Squad representative. COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-K |...

  • Page 12: Chapter 3: Motion Mount Operation

    To adjust MOTION MOUNT settings, follow the instructions below: NOTE: These menu settings are only accessible when the MOTION MOUNT is installed. 1. Turn on the camera. 2. Go to Menu > Settings > Setup > Lens > Motion Mount. COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-K |...

  • Page 13: Neutral Density (Nd)

    The following message also displays in the MOTION MOUNT menu screen: “High ND with wide apertures may cause bokeh asymmetry”. For more information on bokeh asymmetry, go to “Out-of-Focus Field Modification” on page COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-K |...
  • Page 14 1/81.01 1.91 6.34 √ 1/90.51 1.96 6.50 √ 1/101.83 2.01 6.67 √ 1/128.00 2.11 7.00 √ 1/162.02 2.21 7.34 √ 1/181.02 2.26 7.50 √ 1/203.66 2.31 7.67 √ 1/256.00 2.40 8.00 √ COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-K |...
  • Page 15 In some instances, vignetting may also occur at the edge of the image. This is typical when using lenses with smaller image circles. RED recommends that you do not exceed 4.00 stops of ND when shooting with wide apertures.

  • Page 16: Display Effective Iso

    2. Select the MOTION MOUNT ISO Pull setting that you want: ‒ On: Displays the effective ISO. ‒ Off: Displays actual ISO. 3. Select Close to return to the main screen. The effective ISO displays in yellow. COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-K |...
  • Page 17 To view or change the native ISO, press and hold the ISO value to access the Advanced ISO menu. The native ISO is the first value. NOTE: RED recommends that you follow standard exposure best practices and select your ISO value based ® on the native ISO. COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-K |...
  • Page 18 4.00 stops with “ND Only” selected, the ND value on the main screen overlay turns yellow. A warning message also displays in the MOTION MOUNT menu on the camera. For more information about bokeh asymmetry, go to “Out-of-Focus Field Modification” on page COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-K |...

  • Page 19: Motion Mount Shutter Types

    2. Select one of the following shutter types from the Shutter Type drop-down menu: ‒ Soft: For more information, go to “Soft Shutter” on page ‒ Square: For more information, go to “Square Shutter” on page COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-K |...
  • Page 20 The Soft shutter angle ranges from 62.1° to 194.4°. The available shutter angle range at any given time depends on the selected frame rate. For the most natural and realistic motion, use a Soft shutter angle of 194.4°. Then, adjust the shutter angle if necessary. COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-K |...
  • Page 21 135° 106° None None None None CAUTION: Firmware versions earlier than v5.2.14 allow values outside of these ranges. Settings outside of the supported range result in a double exposure of the frame. COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-K |...
  • Page 22 For the most natural and realistic motion in Square shutter mode, start at a shutter angle of 180°. Adjust the shutter angle from there as needed. COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-K |...
  • Page 23 167° 131° 71° None None None CAUTION: Firmware versions earlier than v5.2.14 allow values outside of these ranges. Settings outside of the supported range result in a double exposure of the frame. COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-K |...

  • Page 24: Map Keys For Motion Mount Settings

    Changes the ND value to 0.48. MOTION MOUNT: ND Only Changes the Shutter Type to “ND Only”. MOTION MOUNT: Soft Shutter Changes the Shutter Type to “Soft”. MOTION MOUNT: Square Shutter Changes the Shutter Type to “Square”. COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-K |...

  • Page 25: Chapter 4: Motion Mount Maintenance

     Store the MOTION MOUNT in a clean, dry environment. CLEAN MOTION MOUNT GLASS As with all optical glass, any type of physical contact with the glass may scratch or damage the surface. RED ® recommends that you clean the MOTION MOUNT glass using physical contact only if absolutely necessary.
  • Page 26 DO NOT sweep the wipe across the glass with your finger. WARNING: DO NOT reuse swabs or wipes, since they may have gathered dirt or debris from the glass. COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-J |...

  • Page 27: Chapter 5: Troubleshoot The Motion Mount

    Camera firmware must be v5.1.14 or later to recognize to MOTION MOUNT. If necessary, load the latest camera firmware, then perform a hardware rediscover. POTENTIAL RESOLUTIONS  Upgrade your camera firmware to v5.1.14 or later from https://support.red.com.  Perform a hardware rediscover. A. Go to Menu > Settings > Maintenance > Rediscover.

  • Page 28: Double Exposures In Captured Footage

     Reduce the frame rate used in the shot to below 109.98 FPS and try again.  Ensure that you are using a recommended shutter angle. For more information, go to “Soft Shutter Angle” on page 20 “Square Shutter Angle” on page COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-J |...

  • Page 29: Appendix A: Technical Specifications

    R E D M O T I O N M O U N T O P E R AT I O N G U I D E TECHNICAL SPECIFICATIONS RED MOTION MOUNT TI PL SPECIFICATION DESCRIPTION Dimensions Height: 3.23" (82.0 mm) Width: 3.23"...

  • Page 30: Neutral Density And Shutter Angles

    0.48 to 2.40 (1.60 to 8.00 stops) ND Only Angle Range 1° to 360° 1. Camera firmware versions prior to v5.2.14 DO NOT limit maximum frame rate. RED recommends using a maximum frame rate of 109.98 ® with a RED MOTION MOUNT .

  • Page 31: Maximum Frame Rates

    1. Maximum frame rates are based on camera firmware v6.1. Values may vary slightly based on the camera firmware version. 2. Maximum frame rates are based on camera firmware v5.2.28. Values may vary slightly based on the camera firmware version. COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-J |...

  • Page 32: Appendix B: Motion Mount Compatibility

    27.73 mm behind the PL mounting flange are not compatible with the MOTION MOUNT. NOTE: Any damage to the MOTION MOUNT Ti PL or the camera system caused by using incompatible lenses (including non-standard PL lenses) or devices is not covered under warranty.

  • Page 33: Compatible Pl Lenses And Devices

    R E D M O T I O N M O U N T O P E R AT I O N G U I D E COMPATIBLE PL LENSES AND DEVICES The MOTION MOUNT Ti PL is compatible with the lenses and devices listed in the table below: COMPATIBLE PL LENS/DEVICE FOCAL LENGTH Angénieux Optimo...
  • Page 34 45mm T2.2 65mm T2.2 RED PRO PRIME 25mm T1.8 35mm T1.8 50mm T1.8 85mm T1.8 100mm T1.8 300mm T2.9 RED PRO ZOOM 17–50mm T2.9 18–85mm T2.9 RED ZOOM 18–50mm T3.0 50–150mm T3.0 COPYRIGHT © 2015 RED.COM, INC 955-0013, REV-J |...

  • Page 35: Incompatible Pl Lenses And Devices

    R E D M O T I O N M O U N T O P E R AT I O N G U I D E INCOMPATIBLE PL LENSES AND DEVICES The MOTION MOUNT Ti PL is NOT COMPATIBLE with the lenses and devices listed in the table below: INCOMPATIBLE PL LENS/DEVICE...
  • Page 36 RED DIGITAL CINEMA COPYRIGHT© 2015 RED.COM, INC. All trademarks, trade names, logos, icons, images, written material, code and product names used in association with the accompanying product are the copyrights, trademarks or other intellectual property owned and controlled exclusively by RED.COM, INC.

This manual is also suitable for:

Motion mount ti canon
