Lens; Exposure - Provision ISR UltraVision Series Manual

- You can also adjust the position of the name on your monitor.
For adjusting select POS and press O.
- Use ▲▼◄► to move your name across the monitor and press
O when finished.
◄ ►▲▼ MOVE AND PRESS SET
11

2) Lens

Iris is mechanism which closes and opens allowing more or less
light into the lens.
The camera supports two types of lens:
* MANUAL Iris lens, where the aperture is fixed or set manually
by the user
* DC Iris Lens, in which the aperture is continuously controlled by
the camera to automatically set to the desired level of brightness.
The LENS menu allows you to set the lens which attached to
your camera, and to adjust the desired brightness if DC lens is
used.
- Scroll to LENS using ▲ or ▼
- Use ◄ or ► to select between MANUAL and DC IRIS.
- When selected MANUAL there is no need for more settings.
< MAIN MENU>
1.CAM NAME
2.LENS

3.EXPOSURE

4.DAY/NIGHT
5.WDR/BLC/ECLPS
6.WHITE BAL
7.3D-DNR
8.EFFECTS
9.SPECIAL
0.EXIT
OFF
DC IRIS
AUTO
WDR
ATW
ON
RET
12
