4) Day/Night Settings

Day/Night refers to the mechanism of changing of the optical filter
between IR-cut filter to non-IRC filter. AUTO - set the filter
automatically, DAY - force the usage of the IRC filter (color), and
NIGHT- force usage of IR-PASS filter (and display B&W image).
EXT- is used for Smart-IR mode when the IR-LED board provides
the light info to the camera.
- Scroll to DAY/NIGHT using ▲or▼.
- Choose DAY/NIGHT/EXT/AUTO using ◄ or ►.
1.CAM NAME
2.LENS
3.EXPOSURE
4.DAY/NIGHT
5.WDR/BLC/ECLPS
6.WHITE BAL
7.3D-DNR
8.EFFECTS
9.SPECIAL
0.EXIT
17
< MAIN MENU>
OFF
DC IRIS
AUTO
WDR
ATW
ON
RET
a) If selected AUTO press O to enter D/N AUTO MENU
<D/N AUTO MENU>
D/N LEVEL
FILTER DLY
NIGHT BURST
INITIAL SET
PREVIOUS
D/N LEVEL
Level of darkness in which the camera would switch the IR filter
from Day to Night
- Scroll to D/N LEVEL using ▲or▼.
- Use ◄ or ► to change between LOW/MIDDLE/HIGH.
FILTER DLY
Time (in seconds) to wait before switching between Day/ Night
modes.
- Scroll to FILTER DLY using ▲or▼.
- Use ◄ or ► change Value from 1sec – 60sec.
NIGHT BURST
Allow disable the color burst in the video signal at Night mode.
- Scroll to NIGHT BURST using ▲or▼.
- Use ◄ or ► to switch ON/OFF.
LOW
1 SEC
ON
18
