Provision ISR UltraVision Series Manual page 17

ZOOM
- Scroll to ZOOM using▲ or ▼.
- Use ◄ or ► to select zoom level X1.00 - X6.13.
DZOOM PAN
- Scroll to DZOOM PAN using ▲ or ▼.
- Use◄ or ► to select PAN LEVEL -100 - +100.
- Use◄ for left, ► for right.
DZOOM TILT
- Scroll to DZOOM TILT using ▲ or ▼.
- Use ◄ or ► to select TILT LEVEL -100 - +100
- Use◄ for up, ► for down.
PREVIOUS – Return to previous menu
IMAGE FREEZE
Pausing the live image.
- Scroll to IMAGE FREEZE using▲ or ▼.
- Use ◄ or ► to select ON/OFF.
<EFFECTS MENU>
DZOOM MODE
IMAGE FREEZE
D-EFFECT
COLOR
CONTRAST
SHARPNESS
CR GAIN
CB GAIN
INITIAL SET
PREVIOUS
31
OFF
OFF
OFF
ON
50 -----|----
50 -----|----
50 -----|----
50 -----|----
Note:
When selected IMAGE FREEZE- ON DZOOM MODE
won't be available and the --- Sign will appear.
D-EFFECT
Help you with extreme mounting of the camera
- Scroll to D-EFFET using ▲ or ▼.
- Use ◄ or ► to select between OFF/V-FLIP/MIRROR/ROTATE.
Example:
OFF
V-FLIP
MIRROR
ROTATE
32
