<ECLIPSE MENU>
AREA SETTING
ALL AREA SET
MASK COLOR
ECLPS LEVEL
GAIN CONTROL
PREVIOUS
ECLPS LEVEL
You can choose the ECLIPSE LEVEL between 1–5.
Higher values will increase start the masking at higher level.
- Scroll to ECLPS LEVEL using ▲ or ▼.
- Use◄ or ► to set a level between 1-5.
GAIN CONTROL
You can set an automatic control for the ECLIPSE LEVEL gain.
- Scroll to GAIN CONTROL ▲ or ▼.
- Use◄ or ► to select ON/OFF.
PREVIOUS – Return to previous menu
23
OFF
GRAY
1----|----
OFF

6) White Balance Settings

White balance setting can be adjusted according to the color
temperature of object.
- Scroll to WHITE BAL using ▲ or ▼.
- Use◄ or ► to select between ATW / COL-ROLL / PUSH /
MANUAL.
< MAIN MENU>
1.CAM NAME
2.LENS
3.EXPOSURE
4.DAY/NIGHT
5.WDR/BLC/ECLPS
6.WHITE BAL
7.3D-DNR
8.EFFECTS
9.SPECIAL
0.EXIT
ATW
In outdoor environment the color temperature is between
2500°K~9500°K,
For that it's recommended to use ATW.
COL-ROLL
In indoor environment, the color temperature is between
2000°K~20000°K.
For that it's recommended to use COL-ROLL.
OFF
DC IRIS
AUTO
WDR
ATW
ON
RET
