Provision ISR UltraVision Series Manual page 12

b) If selected BLC press O to enter BLC MENU.
BLC is used when you have a WDR scene, and you want to see
the DARK zone, and you do not mind if the bright zone would be
saturated.
- Use ◄or► for selecting BLC level between
LOW/MIDDLE/HIGH.
<BLC MENU>
BLC LEVEL
PREVIOUS
PREVIOUS – Return to previous menu
c) If selected Eclipse press O for entering ECLIPSE MENU.
ECLIPSE is mainly used when you want to see cars at night,
and want to mask the car strong head-lights.
<ECLIPSE MENU>
AREA SETTING
ALL AREA SET
MASK COLOR
ECLPS LEVEL
GAIN CONTROL
PREVIOUS
21
LOW
OFF
GRAY
1----|----
OFF
AREA SETTING
- Scroll to AREA SETTING using ▲ or▼ and press O.
Inside you have 16 in depended ON/OFF areas that you can set
manually according to the requirements of the actual
environment.
ON OFF
OFF OFF
OFF OFF
OFF OFF
Use ◄ or ► to move across the screen and use ▲or▼ to set ON/OFF.
Press O anywhere on the screen to return to ECLIPSE MENU.
ALL AREA SET
Instead of setting each area individually you can select or
deselect all areas.
- Scroll to ALL AREA SET using ▲ or ▼.
- Use◄ or ► to set ON/OFF.
MASK COLOR
You can choose the color of the eclipse mask.
- Scroll to MASK COLOR SET using ▲ or ▼.
- Use◄ or ► to select a color - GREY, D.GREY, BLACK.
OFF OFF
OFF OFF
OFF OFF
OFF OFF
22
