- Scroll to STABILIZER using ▲ or ▼.
- Use ◄ or ► to set ON/OFF.
L/L SYNC
The Line-Lock (L/L) feature allows the camera to synchronize its
frame rate to the power line phase. The function is only available
when the camera is operated by AC power. It allows the reduction
of the fluorescent lights color rolling effect. When using 12v DC
power, the camera is automatically set to internal (INT) synchroni-
zation mode.
MONITOR TYPE
You can choose the type of screen you are working with between
CRT/LCD.
- Scroll to MONITOR TYPE using ▲ or ▼.
- Use ◄ or ► to select CRT/LCD.
FACTORY RESET
Restore all settings to factory default settings.
- Scroll to FACTORY RESET using ▲ or ▼.
- Press O for resetting.
COMM SETTINGS
- Scroll to SPECIAL MENU using ▲ or ▼.
<SPECIAL MENU>
MOTION DET
PRIVACY MASK
LANGUAGE
STABILIZER
L/L SYNC
MONITOR TYPE
FACTORY RESET
COMM SET
PREVIOUS
41
OFF
OFF
ENG
OFF
INT
LCD
- Press O and the COMM SETTING MENU will appear.
<COMM SETTING MENU>
PROTOCOL
CAMERA ID
BAUD RATE
SAVE/REBBOT
PREVIOUS
PROTOCOL – PELCO-D (Unchangeable setting).
Camera ID
You can set an ID number for your camera.
- Scroll to CAMERA ID using ▲ or ▼ and press O, the
SET CAMERA ID menu will appear.
CAMERA ID
DISPLAY ID
ID POSITION
PREVIOUS
Camera ID - Default 001
- Scroll to CAMERA ID using ▲ or ▼.
- Use ◄ or ► to select an ID number 0 – 255.
PELCO-D
4800
<SET CAMERA ID>
001 |------------
ON
