Q PTT SWITCH [PTT] (p . 12)
Push and hold to transmit ; release to receive.
© POWER/VOLUME CONTROL [PWRNOL]
r .
Rotate to turn power on and off.
k .
Rotate clockwise to increase volume and counterclock-
wise to decrease volume .
©EXTERNAL SPEAKER AND MICROPHONE JACKS
[SP/MIC]
Connect an optional speaker-microphone or headset, if de-
sired . The internal microphone and speaker will not func-
tion when either is connected. (See p. 37 for options.)
O External connection
ow
NOTE : When connecting or disconnecting an external
speaker-microphone, first turn off power to the transceiver.
60---
Remot
k
~
[SP[
PTT
O
ANTENNA CONNECTOR (p . 1)
Connects the supplied antenna.
00
Audio out
(e n)
-0o
This connection
does not apply
when a conden-
sor microphone
is connected.
© EXTERNAL DC POWER JACK [CHARGE]
Connect a 13 .5 to 16 V DC power source using optional
cables, CP-12L or OPC-254L, to charge the batteries, or
connect the BC-1 10A/DN wall charger for charging .
V CAUTION:
This connection is for charging only . Power
to the transceiver must be turned off during charging .
O
TX INDICATOR [TX] (p . 12)
Lights red while transmitting .
O
UP/DOWN KEY ["]/[V]
1-*
In VFO mode, increment or decrement the dis-
played frequency according to the set tuning
steps. (p . 11)
~" In memory mode, increment or decrement the
selected memory channel . (p . 13)
~" In initial set mode, select item conditions . (p . 28)
O
PANEL DESCRIPTION
0
MONITOR KEY [
4
(MONI)] (p . 13)
Push and hold this switch to force the squelch
open ; release to close it again .
k . +
Push twice to keep the squelch open ; push
again to close it .
%*While pushing [PTT], push this switch to trans-
mit a 1750 Hz tone signal . (Europe version only)
ii* When a digit is mistakenly input, push [
] and
input from the beginning .
O
DIAL SELECT KEY [
4 ]
(p . 12)
Push this switch one or more times to select the
dial select step for frequency tuning .
