SECTION 2:

INTRODUCTION

2.01 Overview

Plasma is a gas which has been heated to an extremely
high temperature and ionized so that it becomes elec-
trically conductive. The plasma arc cutting process uses
this plasma to transfer an electrical arc to the work-
piece. The metal to be cut is melted by the heat of the
arc and then blown away.

2.02 General Specifications

System Descriptions
Maximum Output
Input Voltage 230V
Input Voltage 400V CE
Frequency
Input Power 230V 1 Phase
Input Power 230V 3 Phase
Input Power Fuse, 1 Phase
Input Power Fuse, 3 Phase
Input Power 400V
Input Power Fuse, 3 Phase
No Load Voltage
Load Voltage
Output Current
Post-Flow time
Operating Air Pressure
Maximum Air Pressure
Air flow
System *Duty Cycle Ratings
at Ambient Air Temperatures
of 40° C / 104° F.
System *Duty Cycle Ratings
at Ambient Air Temperatures
of 40° C / 104° F.
System *Duty Cycle Ratings
at Ambient Air Temperatures
of 40° C / 104° F.
Maximum Cutting Capacity
Dimensions (W x D x H)
Net Weight
Introduction
C-70A
70 Amps
Single and
Three Phase
Three Phase
50/60Hz
67 Amps (15.4 kVA )
37 Amps ( 8.5 kVA )
230V - 80 Amp
230V - 40 Amp
24 Amps (9.6 kVA)
400V - 30 Amp
250V
108V
25-70 Amps
10 Seconds
75 psi (5.2 bar)(.52
Mpa)
125 psi (8.6 bar)(.86
Mpa)
400 scfh
6.6 scfm
(188.7 lpm)
35% @ 70Amps
60% @ 60Amps
100% @ 50Amps
1" (25mm)
9.7" x 21.7" x 16.5"
(245 mm x 550 mm x
420 mm )
66 lbs. (30 kg)
2-1
CUT
70A
CUT
60A
CUT
50A
35% (3.5 min)
60% (6 min)
NOTE:
*Duty Cycle is the percentage of time the sys-
tem can be operated without overheating. Duty
cycle is reduced if primary input voltage (AC) is
low or the DC voltage is higher than shown in
previous chart.

2.03 Features

• RELIABLE AND POWERFUL - This inverter
based power supply operates on standard 230V
single or three phase power.
• POWERFUL CUTTING PERFORMANCE -
Maximum cutting capacity is 1" (25mm).
• CUTS MOST METALS - Useful for most metals
such as stainless steel, aluminum, mild steel, cop-
per and alloys.
• NO HIGH FREQUENCY - Starts without high-
frequency so it won't interfere with controls or
computers.
• MORE TORCH, LESS MONEY - The SL100™
1Torch™ provides state of the art technology and
performance of more expensive torches.
OFF
OFF
100% (10 min)
Manual 0-4699
