Thermal Dynamics C-70A CUTSKILL Service Manual page 34

7.01 Parts List Power Supply
Item Number Quantity
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
24
25
26
27
28
29
30
31
32
33
Parts List
Description
1 Side Cover-Right
1 Cover Assembly
1 Side Cover-Left
1 Switch-Toggle
1 Knob
1 Cable Ground PG29
1 Front Panel Assembly
1 Circuit Breaker
1 Volume
1 Air Assembly
1 Case, Back
1 Cable Ground PG21 (CE Version Only)
1 Fan
1 Connector
1 Case, Torch Cover
1 Case, Bottom
1 Capacitor Assembly
1 Heat Sink Assembly
1 Reactor
1 Main Transformer Assembly
1 PCB-Torch Filter
1 Pilot Relay Assembly
1 PCB-Control
1 PCB-Input Filter (CE Version)
1 Terminal Block (Non CE Version)
1 PCB-PWM Drive
1 Control Transformer 400V
1 Solenoid Assembly
1 Current Sensor
1 Resistor
1 PCB-input magnet
1 Bracket
1 Magnet
1 Case, Top
7-2
Catalog Number
9-7214
9-0329
9-7213
9-0333
9-0334
9-0291
9-0382
9-7177
9-0335
9-0330
9-0331
9-0296
9-7164
9-0305
9-0337
9-0336
9-0350
9-0349
9-7110
9-0348
9-7121
9-0340
9-7189
9-0363
9-0341
9-7120
9-7151
9-0343
9-7174
9-0344
9-0346
9-0345
9-0347
9-0351
Manual 0-4699
