EGi DOMOS2 User Manual page 73

auxiliary modules
40510
services
The domotic central unit allows you to program the connection of one or more
relays of 40540 module. It is possible to program the time for the service activation
and deactivation. To configure this, do as follows:
1. Press the MENU key several times until SERVICE is displayed.
2. Press OK.
3. SERVICIE 07 is displayed. The number 07 blinks. To select other service,
press (OK/+) or (NO/–).
4. Press MENU key . The display shows N SERVIC with the number of
the selected relay down on the right.
5. You may activate (OK/+) o not activate (NO/–) the SERVICE (relay).
6. If the MENU key is pressed now, SERVICE will be displayed, and 5-MF will
blink. Use (OK/+) and (NO/–) to select the days or the alarm type to be
activated by this output of the 40540 relay module.
5-MF: Monday to Friday.
6-MS: Monday to Saturday.
2-SS: Saturday and Sunday.
7-MS: Monday to Sunday.
7. Once the SERVICE has been configured, press MENU to configure the
activation time of the relay. ON TIME is displayed.
Press (OK/+) and (NO/–) to adjust the hour. Once the hour has been
adjusted, press MENU key to adjust the minutes in the same way.
8. Press MENU key again to configure the deactivation time of the relay.
OFF TIME will be displayed.
Press (OK/+) and (NO/–) to adjust the hour. Once the hour has been
adjusted, press MENU key to adjust the minutes in the same way.
s e r v i c e
t i m e o n
presence simulation
The domotic central unit allows the system to simulate the presence of people at home, giving you home
security when nobody is at home. Program your control units and the domotic central unit will turn them on,
when the presence simulation mode is activated.
FIRE INTR
The domotic central unit can reproduce its own working pattern or use the LEARNING mode. Using the learning
GAS NONE
mode, the central unit learns the daily use of the control units and reproduces it when the presence simulation
FLOOD
mode is activated. To activate the presence simulation mode, do as follows:
1.
2.
3.
4.
5.
6.
73
st
1
n s e r v i c
0 7 y e s
nd
2
st
1
t i m e o f f
1 5 : 2 5 1 6 : 2 3
nd
2
7
Press the MENU key until SIMULAT is displayed.
Press (OK).
Select (OK/+) to activate the automatic simulation or (NO/–) to deactivate it.
If you select (NO/–), and press MENU, you can select between 10 memory positions, which correspond
to the control units with zone no. 1...10 of the installation.
Select the corresponding memory position and press MENU key
A menu to activate or not activate the presence simulation mode will be displayed. Press (OK/+) to select
YES and then press MENU key .
st st
1 1
s e r v i c e
7 - m s
nd nd
2 2
7 7
t i m e o f f
1 7 : 2 3
7 7
.
st
1
t i m e o n
1 5 : 2 5
nd
2
