EGi DOMOS2 User Manual

Hide thumbs Also See for DOMOS2:

Advertisement

Quick Links

See also: Installation Manual
english
user's manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the DOMOS2 and is the answer not in the manual?

Questions and answers

Related Manuals for EGi DOMOS2

Summary of Contents for EGi DOMOS2

  • Page 1 english user's manual...
  • Page 2 We hope you enjoy the services of your EGi There are other modules available that give installation, designed to give you years of additional services to the installation when exceptional and reliable service.

  • Page 3: Simbols

    Turned on Intercom function Flooding alarm main features of the DOMOS2 series Turned off Clock Intruder alarm (1 and 2) • Up to 5 audio programs. • Remote control over the audio sources. Timer Miscellaneous • Control over the installation with a remote...

  • Page 4: Information

    ABOUT THIS MANUAL INFORMACIÓN EMC We have taken all efforts to make the contents of this manual reliable and updated. However, EGi does not Domos2 devices comply with the ER,EN 55022 regulations. Operation is subject to the following two conditions: guarantee the accuracy of the contents which are subject to change without previous notice.

  • Page 5: Table Of Contents

    index Simbols Information 40010, 40020, 40040, 40050, 40060 Central units for DIN rail mounting 40070, 40080, 40090, 40200 Central units for Ø60 mm box 40230, 40240, 40250, 40260, 40270, 40280, 40620 Controls units 40410, 40420, 40520 Interface modules 40140, 40150, 40160, 40610, 40510 Auxiliary modules Accessories www.egiaudio.com...
  • Page 6 3 RCA AUDIO INPUT (3 AUDIO PROGRAMS) overview Central units in a DOMOS2 installation, distribute audio and manage additional services provided by the series. Central Units can manage up to 50 zones and, depending on the model, distribute up to 3 general stereo EGi ref.
  • Page 7 To reset or change the configuration on a system using the central unit Message recording is allowed when using control units EGi ref. 40250, 40260, 40270 and 40280. Please module EGi ref. 40050 or 40010, the control unit configuration manual refer to the control unit manual for details.
  • Page 8 The RCA inputs in the central unit connect to the music source. This music source can be controlled through the infrared capsule EGi ref. 40110, using the sound system own remote or EGi 40100 or 40130 from the room where it is being listened, just pointing the remote control to the EGi in-wall control unit.
  • Page 9 Central Units can manage up to 50 zones and, depending on the model, distribute up to 3 general stereo audio programs. The central module must be connected to a power supply unit (EGi ref. 40710, 40720 or 40730) that provides the needed power for proper function of the system.
  • Page 10 CLOCK CONFIGURATION Once the DOMOS2 system has been correctly installed, the different modules must be configured for proper One of the central unit main functions is to manage the services provided by performance whitin the system. Each room is called a ZONE.
  • Page 11 central units 40020, 40040, 40060 for DIN rail mounting audio functions SELECT A RADIO STATION OR RCA AUDIO FOR A PROGRAM Depending on the model, 1 (40020), 2 (40040) or 3 (40060) audio programs Once the program that is tuning a radio station is selected, if you want to change this radio station, please can be configured in the system.
  • Page 12 central units 40020, 40040, 40060 for DIN rail mounting DELETE A STORED RADIO STATION To configure this service: Press MENU key until AUDIO appears on the screen. From this menu, audio can be activated or Press MENU key until CARILLON appears on the screen. Use (OK/+) deactivated using (OK/+) or (NO/–).
  • Page 13 (OK/+) or (NO/–). Your EGi DOMOS2 system can control and listen any zone of the installation. BELL FUNCTION This service is used from the control units, altough it must be activated in the central unit.
  • Page 14 Press MENU key several times until BLOCK appears. From this menu, On top of the previous services, your DOMOS2 central unit provides the following parameters and services. the service can be activated or deactivated using (OK/+) or (NO/–). To configure the rest of adjustments, please follow the procedure ahead: Press MENU key several times until MISCELL appears.
  • Page 15 central units 40020, 40040, 40060 for DIN rail mounting AUTOSCAN OFFSET The AUTOSCAN service automatically scans the FM band and stores OFFSET is a function used to compensate the internal clock of the system and correct the fluctuations that the radio stations with the highest signal level. might appear due to temperature or other evironmental conditions.
  • Page 16 central units 40020, 40040, 40060 for DIN rail mounting To change the language, press (OK/+) or (NO/–) to choose from the available languages. TECHNICAL SERVICE INFORMATION If you need technical support on the product, it is possible that you are asked about the software version and other parameters.

  • Page 17: Central Units For Ø60 Mm Box

    1 USB INPUT overview 40090 Central unit gives additional services to your DOMOS2 installation. It provides the clock for the The function of the DOMOS2 central units ref. 40070 and 40080 is to give installation and manages room-to-room intercom, acoustic surveillance (baby sitter) and SOS function.
  • Page 18 Connect a 40110 wire to the IR connector of the 40070 central unit and put the capsule on the audio source (from MEM 1 to MEM 9). sensor in order to control the audio source from any room with a DOMOS2 in-wall control unit, using the RADIO STATION SEARCH remote control of the audio source or 40100/40130 remote control.
  • Page 19 SAV E SAV E D EGi control units are factory calibrated to deliver optimum performance. Nevertheless, there might be situations, where FM reception is not good enough. In those situations, manual gain adjustment could sort out the problem. To perform this operation, do as follows: Press the MENU key several times until ADJUSTMS is displayed.
  • Page 20 central units 40070, 40080, 40090, 40200 Ø 60mm box BLOCKING FUNCTION SOFTWARE VERSION Using this funtion, only one control unit will control the program. If you need technical support on the product, it is possible that you are asked about the software version. To check this parameter, do as follows: If you select NO, any control unit can change the radio station of the program at any moment.

  • Page 21: Central Units For Din Rail Mounting

    CLOCK + INTERCOM + SURVEILLANCE + SOS + DOOR PHONE Press the MENU key several times until SET PR is displayed. Press (OK/+) and (NO/–) to select the number of the program between EGi ref. 40090 1 and 3. Menu key.
  • Page 22 central units 40070, 40080, 40090, 40200 Ø 60mm box other configurations SOFTWARE VERSION If you need technical support on the product, it is possible that you are asked BACKLIGHT ADJUSTMENT about the software version. To check this parameter, do as follows: Press the MENU key several times until ADJUSTMS is displayed.
  • Page 23 NOTE: You can abandon the programming at any time by pressing the Exit MENU key several times. EGi ref. 40200 WARNING: If you change the language on the central unit, all control units configured in AUTO mode will also change the language.

  • Page 24: Controls Units

    3 AUDIO PROGRAMS + IR 40240 3 AUDIO PROGRAMS + LOCAL FM + IR overview EGi ref. 40230 and 40240 control units allow the configuration of a wide variety of audio and other functions, that DOMOS2 provides. EGi ref. 40240 The information is displayed using a high bright 7 segments device, the model EGi ref.
  • Page 25 From the central unit: To activate the control unit, press (ON). When powered on, the control unit If your installation includes a central unit EGi ref. 40020, 40040 y 40060, the installation reset can be retrieves the last values before switching off.
  • Page 26 Press repeatedly the MENU key until AUD appears on the display. From your EGi ref. 40230 and 40240 control unit, you will have control over the audio programs in your Then, press (OK/+) to visualize PR-1. (If you are tuning a local program, installation.
  • Page 27 control unit 40230, 40240 Choose the memory position to store the radio station pressing (OFF/–) ECUALIZATION (bass and treble), BALANCE AND VOLUME CONFIGURATION or (OK/+) shortly. Once you have chosen the memory position, press If you want to make modifications to the audio, please follow these instructions: (OK/+) for 2 seconds.
  • Page 28 CH appears. Press (OFF/–) or (OK/+) to choose NO (deactivated) or YES (activated). COMMUNICATE WITH DIFFERENT ZONES An added feature of the DOMOS2 system is the ability to intercommunicate to any zone of the installation. – A D J c A – 5 Press MENU key a few times until INT appears on the display.
  • Page 29 BELL FUNCTION Then, press (OK/+). VIGL appears. All the DOMOS2 Central units are ready to have the door bell connected. Press (OFF/–)and (OK/+) to select YES (activated) or NO (deactivated). When the door bell is rang, a tune is generated in the areas of the installation The zone under surveillance LED lights with the service activated.
  • Page 30 control unit 40230, 40240 LISTEN FUNCTION Press MENU key a few times until LS appears on the display. Press (OFF/–) and (OK/+) to select YES (activated) or NO When the baby sitter configuration is finished, another control unit must be set to listen the surveilled zones. (deactivated).
  • Page 31 control unit 40230, 40240 ALARM CLOCK FUNCTION AUTO SWITCH OFF (SLEEP) The control unit has an embedded alarm clock that will let you connect the The control unit includes an auto timer. If this function is ON, the control unit will automatically switch off audio system at the given time or switch on a buzzer.
  • Page 32 control unit 40230, 40240 Press (OFF/–)and (OK/+) to select YES (activated) or NO (deactivated). LANGUAGE SELECTION If the service is activated, the clock LED lights. The menu language can be selected. To choose your language, please do as follows: Press MENU key 4 times AUD >...
  • Page 33 control unit 40230, 40240 SOFTWARE VERSION If you need technical support on the product, it is possible that you are asked about the software version. To check this parameter: Press MENU key 4 times AUD > INT > VIG > until ADJ. Then, press (OK/+) for two seconds.
  • Page 34 LCD. 3 AUDIO PROGRAMS + IR 40260 LCD. 3 AUDIO PROGRAMS + LOCAL FM + IR overview EGi ref. 40250 y 40260 control units allow the configuration of a wide variety of audio and other functions, that DOMOS2 provides. EGi ref. 40260 The information is displayed using a LCD display, the model EGi ref.
  • Page 35 For swithing off, keep the key (OFF/-) pressed. From the central unit: If your installation includes a central unit EGi ref. 40020, 40040 and 40060, the installation reset can be ZONE ASSIGNMENT made from this unit.
  • Page 36 To select a radio station in the local tuner or the central unit, please do as audio functions follows: From your EGi ref. 40250 and 40260 control unit, you will have control over the audio programs in your Press repeatedly the MENU key until AUDIO appears on the display.
  • Page 37 control unit 40250, 40260 By pressing the MENU key again, SCAN will appear on the display. s e a rch sav e Press shortly (OFF/–) or (OK/+/ON) to increase or decrease the tuned frequency manually. If you make that press longer, the search will be performed automatically, and SRCH will appear on the display.
  • Page 38 COMMUNICATE WITH DIFFERENT ZONES Nevertheless, there might be situations, where FM reception is not good enough. In those situations, manual An added feature of the DOMOS2 system is the ability to intercommunicate gain adjustment could sort out the problem. to any zone of the installation.
  • Page 39 CARILLON FUNCTION DOOR PHONE This function only appears in the control unit, if the phone door module EGi ref. 40410 or 40420 is This function appears when the service is active in the Central unit. installed and activated in the central unit.
  • Page 40 control unit 40250, 40260 LISTEN FUNCTION Press the MENU key several times until BELL appears. When the babysitter configuration is finished, another control unit must be set Press (OFF/–) or (OK/+/ON) to choose NO (deactivated) or YES (activated). to listen the surveilled zones. This way, you will listen any sound coming from DOOR PHONE BELL these zones.
  • Page 41 control unit 40250, 40260 other functions WAKE-UP appears on the display. Press (OK/+/ON) again to configure the time. The hour blinks. DO NOT DISTURB Adjust the time with (OK/+/ON) or (OFF/–). Press MENU key to configure the minutes the same way. This function mutes any communication from the bell, entry phone or intercom Press now MENU key to reach the BUZZR menu.
  • Page 42 control unit 40250, 40260 AUTO SWITCH OFF (TIMER) MESSAGE RECORDER The control unit includes an auto timer. If this function is ON, the control unit will automatically switch off An added value of your control unit, is the message recording with a maximum in 30 minutes.
  • Page 43 control unit 40250, 40260 other adjustments TIME ADJUSTMENT The control unit can set the time for the installation or get it from the Central Unit. BACKLIGHT ADJUSTMENT If you need to adjust the time from the control unit, do as follows: Using this, you will modify the intensity of the display light when it is on Press MENU key 4 times AUDIO >...
  • Page 44 control unit 40250, 40260 LANGUAGE SELECTION Press (OK/+/ON) for 2 seconds The menu language can be selected. To choose your language, please do as follows: WAKE-UP appears on the display. Press again (OK/+/ON) several times until VERS appears on the display. Press the MENU key 3 times, AUDIO >...
  • Page 45 The information is displayed using a blue backlighted LCD display and controlled through a swing system for easy menu access. The model EGi ref. 40280 includes a local FM tuner and they can supply up to 3 audio programs. Using these control units, the following services can be accessed: •...
  • Page 46 From the central unit: ZONE ASSIGNMENT If your installation includes a central unit EGi ref. 40020, 40040 and 40060, Each room is known as a ZONE. the installation reset can be made from this unit. Please refer to your central This procedure will assign a zone to each control unit, so that the central unit will detect and assign functions unit manual for detailed information.
  • Page 47 Press (OK/+/ON) for a few seconds and navigate using (OK/+/ON) and From your EGi ref. 40270 and 40280 control unit, you will have control over the audio programs in your (OFF/–) until RSET appears on the display. installation.
  • Page 48 control unit 40270, 40280 VOLUME CONTROL PROGRAM CHANGE Choose the memory position to store the radio station pressing (OFF/–) or (OK/+/ON) shortly. Once you have chosen the memory position, press (OK/+/ON) for 2 seconds. The frequency will stop flashing and AUD A U D A U D 8 7 .
  • Page 49 To choose the balance level, press again the MENU key and use An added feature of the DOMOS2 system is the ability to intercommunicate to any zone of the installation. (OFF/–) and (OK/+/ON) to send power to the left or right speaker.
  • Page 50 C A R I L L O N Y E S DOOR PHONE This function only appears in the control unit, if the phone door module EGi ref. 40410 or 40420 is END COMM installed and activated in the central unit.
  • Page 51 40270, 40280 BELL FUNCTION surveillance functions All the DOMOS2 Central units are ready to have the door bell connected. BABY SITTER FUNCTION When the door bell is rang, a tune is generated in the areas of the installation Using this function, you will be able to listen any room in the installation and check easily if a baby is resting with the service activated.
  • Page 52 control unit 40270, 40280 SURVEILLED ZONE LISTEN FUNCTION ALARM CLOCK FUNCTION The control unit has an embedded alarm clock that will let you connect the audio system at the given time or switch on a buzzer. S U RV E I L M N I T O R E D S U RV E I L L I ST E N...
  • Page 53 control unit 40270, 40280 Press (OK/+/ON). A L A R M A L A R M B U Z Z E R Press the MENU key several times until ADJUSTM appears. : 1 5 Press (OK/+/ON) for 2 seconds. WAKE-UP appears on the display. Press the MENU key shortly until TIMER appears on the display: Press (OK/+/ON) or (OFF/–) to choose the disconnection time between 1 and 59 minutes.
  • Page 54 control unit 40270, 40280 MESSAGE RECORDER more adjustments An added value of your control unit, is the message recording with a maximum of 20 secs. BACKLIGHT ADJUSTMENT Press the MENU key 3 times, AUDIO > INTERCOM > SURVEIL > until MISCELL is displayed. Using this, you will modify the intensity of the display light when it is on Press (OK/+/ON).
  • Page 55 The menu language can be selected. To choose your language, please do as follows: EGi ref. 40270/40280 control unit, includes a temperature probe. By default, the value registered by this probe is shown when the control unit is on stand-by.
  • Page 56 control unit 40270, 40280 SOFTWARE VERSION If you need technical support on the product, it is possible that you are asked M I S C E L L A D J U ST M A D J U ST M about the software version.
  • Page 57 RELAY ACTIVATION the control unit is installed, you will be able to control the devices locally If the DOMOS2 installation includes a relay module EGi ref. 40540 linked to the 0 zone (GENERAL), the connected. control unit will be able to activate or deactivate the relays for the GENERAL SERVICES 7, 8, 9 and 0 To control these services, proceed as follows: (please refer to the domotic module EGi ref.
  • Page 58 Y E S ALARM VISUALIZATION If your DOMOS2 installation includes a Domotic Central Unit or domotic modules, when an alarm is generated by a sensor connected to them, the control unit will display the alarm type generated. FIRE, WATER, GAS or INTR will come up on the display.
  • Page 59 Once the atmosphere has been selected, press the MENU key to configure the intensity of the first lamp programmed for this atmosphere EGi ref. 40620 Press (NO/–) to decrease the light intensity or press (OK/–) to increase the light intensity from 0 (switch off) to 10 (max.
  • Page 60 control unit 40620 other adjustments SOFTWARE VERSION 40620 Lighting control unit allows you to make more adjustments, apart from programming lighting To know the software version of the product, do as follows: atmospheres. Long press on the MENU key twice. ZONE will be displayed. Short press on the MENU key again until VER is displayed.

  • Page 61: Interface Modules

    DOOR NUMBER ASSIGNMENT (1 STEP) It allows you to open the door or cancel the intercom using the DOMOS2 in- Each installation allows the connection of 3 door phones in order to control up to 3 different doors. Each wall control units.
  • Page 62 In case that the brand name of your door phone is not included on the list or your door phone interface does FERMAX ® not work properly, after selecting the correct brand name; please contact EGi Technical Assistance Service. CEMELIT ®...
  • Page 63 interface modules 40410, 40420 door phone use Select communication with the zone number, that has been previously assigned to the door phone The use of the module in a everyday situation is described below. (please consult “Module Configuration”). Hold the key to initiate communication.
  • Page 64 SOS alarm notice. Home electrical appliances control (4 general relays + 1 internal relay). Communication through telephone. • Intercom to communicate with the DOMOS2 system zones (from 0 to 9) through telephone. Connection to the main BUS. Status LED indicator.
  • Page 65 interface modules 40520 functions FUNCTION MENU FUNCTION GSM interface module interacts over: Access Deactivate the alarm that has gone off. • Alarms. alarm menu Arm intruder alarm. Disarm intruder alarm. • Intercommunication. Go back to the main menu • Relays. Access Talk to the selected zone (one key press In two situations:...
  • Page 66 interface modules 40520 Press the MENU key until GSM is displayed. The message must be as follows: Press (OK) to access to the screen. Introduce the PIN code of the card that has been inserted into the Incoming The telephone can call the module. GSM module.
  • Page 67 interface modules 40520 G S M S E T G S M S E T S M S G S M O K WARNING: Your installer has inserted a SIM card into the GSM interface module. Check that you have all documents and the card PIN number.

  • Page 68: Auxiliary Modules

    40140 Auxiliary module has one stereo audio input (1) through a 3.5 mm jack connector. It allows the DOMOS2 system connection of an external audio source using the EGi wire of ref. 0501 or 0503. It also has one stereo headphones output (2).
  • Page 69 40150 module (5), one 3.5 mm jack headphones output, and one stereo audio input (through a 3.5 mm. jack connector) to adapt any audio source using the EGi wire of ref. 0501 or 0503. It is possible to connect 2 modules of EGi ref. 40160.
  • Page 70 auxiliary modules 40610 card reader configuration The module has two different types of cards. The MASTER card allows you to make or cancel user cards. The system allows up to 8 user cards MAKE A NEW USER CARD Pass the MASTER card over the module. Then, before 10 seconds, pass the user card over the module.
  • Page 71 DOMOTIC CENTRAL UNIT + PC CONNECTION overview Your domotic central unit can manage different sensors for detecting fire, gas, flooding or intruders. EGi ref. 40510 It also allows the configuration of different domotic scenes, home access control, and communication with other modules of the installation, such as 40520 GSM interface module –...
  • Page 72 auxiliary modules 40510 alarms INTRUDER ALARM Your domotic central unit can manage different sensors for detecting fire, gas, flooding or intruders. To It allows to configure the intruder sensors. configure it, do as follows: Press the MENU key . INTRUDER is displayed. When pressing (OK/+), T.
  • Page 73 auxiliary modules 40510 services s e r v i c e n s e r v i c s e r v i c e t i m e o n The domotic central unit allows you to program the connection of one or more y e s 7 - m s : 2 5...
  • Page 74 auxiliary modules 40510 TIME ON is displayed. Use (OK/+) and (NO/–) to adjust the time for the activation of the presence access control simulation mode in the selected memory position. Once this has been done, press MENU key Your domotic central unit allows access control and presence detection through 40610 module.
  • Page 75 auxiliary modules 40510 To configure a domotic scene, do as follows: S C E N e s e r v - 7 b l i n d s t i m e Press the MENU key several times until SCENE is displayed. y e s d o w n y e s...
  • Page 76 auxiliary modules 40510 • Module software version. RELAY ASSIGNMENT 40510 Domotic central unit has a local relay that can be activated if a specific • Language selection. alarm goes off or any of them. To configure this parameter, do as follows: To configure these parameters, do as follows: Press MENU key several times until ADJUSTMS is displayed.
  • Page 77 auxiliary modules 40510 LANGUAGE SELECTION Press MENU key several times until ADJUSTMS is displayed. Press (OK/+) for at least 2 seconds. TIME is displayed and the hour digit blinks. Press MENU key several times until ENGLISH is displayed. To change the language, press (OK/+) and (NO/–). If you select ID AUTO, the language will be set by default.

  • Page 78: Accessories

    These universal remote controls can program your home devices, so you will box or the G14A loudspeaker for in-ceiling mounting, which delivers exceptional quality sound. be able to control them from your EGi remote control, without using the remote controls of each device.
  • Page 79 In all these cases that are excluded from the guarantee, and every time that the modules are not considered not cover in any case the damages or breakings of the trimming pieces (lattices, as faulty by EGi, the sender should take responsibility of the full amount of the repair, and in the event trims, masks, frames...).
  • Page 80 Avda. Almozara, 79 50003 Zaragoza - SPAIN Tel. +34 976 40 53 56 Fax +34 976 40 53 54 http//: www.egiaudio.com e-mail: info@egiaudio.com...
