overview
Central units in a DOMOS2 installation, distribute audio and manage additional services provided by the series.
Central Units can manage up to 50 zones and, depending on the model, distribute up to 3 general stereo
audio programs.
Central Units ref.40010/40050 have the following specifications:
• 1/ 3 stereo audio programs (RCA audio input).
• Acoustic surveillance (baby sitter).
• Clock (manages the installation clock system. It must be adjusted from the control units).
• Intercommunication (The Central Unit manages this service).
• Message recorder (20 sec. maximum recording time) if the installation provides this service.
• Sound system remote control ( IR Link, infrared remote control for sound system from any room
where a control unit is installed, using EGi ref.40130 or 40100 or the sound system remote control).
NOTE: This service may not work with all remote control units.
• Bell (a tone is generated in all the installation when the door bell rings).
NOTE: This service must be activated wiring the door bell to the Central Unit.
• SOS: Alerts about a dangerous situation or someone in need of help.
• Door entry phone: You can answer a call to the door entry phone from any room with a control unit.
www.egiaudio.com
central units
40010, 40050
for DIN rail mounting
40010
1 RCA AUDIO INPUT (1 AUDIO PROGRAM)
40050
3 RCA AUDIO INPUT (3 AUDIO PROGRAMS)
1
2
3
5
1 Active module.
2 Audio signal present.
3 IR link for remote control.
6
EGi ref. 40050
6
4 RCA audio input.
5 Power connector.
6 Bell connector.
4
