2.4 Button Tags

This subsection describes work with Button Tags in
Tag Printing
1. Every
be laser-printed. Cut the printed foil and insert the tags in the name plates.
2. Every name plate includes a piece of foil, which can be written over manually,
using a waterproof permanent marker, if necessary.
Note
Tag Inserting/Replacing Instructions
®
2N
the name plates. The tags are easy to insert and replace
even without a manual. You need not remove the front panel
and thus are not exposed to the risk of loss of components
while replacing the tags.
1. Loosen the name plate screw using the wrench
enclosed, for example. You can open the name plate
window like a door without losing the tightened screw.
2. Remove the used or blank name tag and insert a new
tag.
3. Close the name plate window and tighten the screw
appropriately.
4. Check the click effect of the buttons: if the button fails
to click properly when pressed (when moved by
approx. 0.5 mm), the tag is too thick or thin. Make
sure that the button clicks when you press it on either
end.
®
2N TELEKOMUNIKACE a.s., www.2n.cz
®
2N Helios IP Uni
Always use waterproof foil (enclosed or other) for the tags. Never use
paper or ink jet printing to avoid damage due to water leakage!
Helios IP Uni provides an intuitive, easy access to
2N
delivery includes a sheet of translucent foil, which can
®
Helios IP Uni .
