SYSTEM DESCRIPTION:

The incoming feed water from a cold supply pipe valve is directed through 1/4"
BLACK tubing and is first passed through a 1 micron Micro-Tec™ sediment
pre-filter. This filter is used to remove excessive turbidity, sand, dust, silt etc.that
may cause the carbon filter to plug up.
The next stage of filtration is a 1 micron carbon block pre-filter. This filter is used
to remove organics and chlorine from the feed water that can damage the
membrane.
The final stage of the system is the R.O. membrane. A high rejection Thin Film
Composite (TFC) membrane is used in this system. This removes as much as
98(+) % of most inorganic salts, all micro-organisms and almost all high molecular
weight organics in the water.
Fig. A: Single-Membrane Filter Diagram
SpectraPure®Inc .
E-mail: spectra@spectrapure.com Visit us on the web www.spectrapure.com
®
Fax 480.894.6109 Fax us toll-free 1.877.527.7873
TFC RO Membrane
(ELIM-MEM-100) &
Housing
Pressure Gauge
1 micron
Carbon Block Filter
(ELIM-CF-1)
1 micron MicroTec™
Sediment Pre-Filter
(ELIM-SF-1)
