RS-232 Interface

Enabling either of these modes will disable USB communications and require you to
default the imager or read the "USB Keyboard" symbol to return to USB.
See RS-232 Interface
RS-232 Default Settings
This mode is the standard way of transferring unformatted, unpacketized data through the
RS-232 port.
You will need to read this symbol whenever you set up RS-232 communications.
Baud Rate (RS-232)
Baud Rate is the rate at which the imager and host transfer data. It only needs to be
changed if necessary to match the host setting.
1200
2400
4800
9600
Save Settings
Mobile Hawk Handheld DPM Imager User's Manual
for detailed steps on setting up the RS-232 Interface.
19.2K
38.4K
57.6K (Default)
115.2K
Communications
4-5
