Illumination Settings by ESP

The Mobile Hawk's illumination settings can also be controlled using the graphic interface
on the Illumination tab in ESP's I/O Parameters view.
Define how many illumination
steps (1 - 8) the imager will cycle
through during its sequence.
Gain can be controlled using
the sliders shown in each Step
dialog when the Gain Control
Manual box is checked.
Mobile Hawk Handheld DPM Imager User's Manual
Click this button to default
settings for the Mobile Hawk
illumination sequence.
Advanced Operations
Click Create Bar Code to
encode illumination settings
in a programming symbol.
Select Low
Resolution
Image for
larger symbols.
Image Enhance
features apply
advanced image
processing to
improve the
readability of the
mark.
8-3
