Macros

Macros can be stored in a macro selection bar, edited in a separate window, and executed
by clicking on the macro name.
Click on Next
Row to see the
next set of
macro buttons.
Clicking on a macro button executes the related command. The command is also sent to
the imager at the same time it is displayed.
Editing a Macro
When you click the arrow next to a any macro and select Edit, the following dialog appears:
Mobile Hawk Handheld DPM Imager User's Manual
When you click Move to Start, the
names of all the macros appear, as
shown at left. Choose which macro but-
ton you want to appear in the first position
at the bottom of the terminal view.
Click on the first arrow here to see Add Macro, Default Macros, and
Move to Start.
When you default macros, the entire macros set is restored to original
commands.
Click on all subsequent arrows
to Edit the associated macros.
You can edit an existing
macro or type in the Macro
Name text field and define it
in the Macro Value text field.
Terminal
9-5
