Hardware installation

The installation of the LANCOM 3550 Wireless base station takes place in the
following steps:
22
Connector for main antenna (if necessary is here the spot to connect Air-
Lancer Extender additional antennas)
Connection for the included power adapter
Reset switch – has two different functions depending on the length of
time that it is pressed:
Restarting the device (soft reset) – push the button for less than five
seconds. The device will restart.
Resetting the configuration (hard reset) – push the button for more
than five seconds. All the device's LEDs will light up green and stay
on. As soon as the reset switch is released, the device will restart with
factory settings.
10/100base-Tx for the connection to the LAN. 10Mbp- or 100Mbp con-
nections are supported. The used transfer speed will automatically be
identified (autosensing).
The LAN connector of the LANCOM 3550 Wireless base station supports
the Power-over-Ethernet standard (PoE). You find further information
about operating with PoE in the info box 'Power-over-Ethernet – elegant
power supply through the LAN wiring'.
Node/hub switch – the sending and receiving lines of the LAN connector
( ) can be crossed within the device for a direct connection of a PC ('hub'
setting ). For connection to a hub or a switch, the switch should be
turned to 'node' setting
WAN connector for DSL or cable modem. 10Mbp- or 100Mbp connections
are supported.The used transfer speed will automatically be identified
(Autosensing).
Connector for diversity antenna
Mounting of ferrite corres – For operating the device it is necessary to
fix the included ferrite cores with the LAN cable, the WAN cable and with
the power adapter cable.
(presetting).
