LANCOM 3550 Wireless
Chapter 10: Appendix
10.2
Contact assignment
10.2.1
LAN interface, 10/100base-TX
8-pin RJ45 socket, as per ISO 8877, EN 60603-7
Connector
10.2.2
WAN interface, 10/100base-TX
8-pin RJ45 socket, as per ISO 8877, EN 60603-7
Connector
76
Pin
1
2
3
4
5
6
7
8
Pin
1
2
3
4
5
6
7
8
Line
T+
T-
R+
PoE/G
PoE/G
R-
PoE/-48 V
PoE/-48 V
Line
T+
T-
R+
–
–
R-
–
–
