LANCOM 3550 Wireless
Chapter 2: Installation
2.3
Status displays, interfaces an hardware installation
2.3.1
Status display
Meanings of the LEDs
In the following sections we will use different terms to describe the behaviour
of the LEDs:
Front side
The LANCOM 3550 Wireless have status displays on the front panel.
Top panel
Two addtional LEDs on the top panel provide a convenient overview of the
most important status information, especially when the device is mounted
vertically.
18
Blinking means, that the LED is switched on or off at regular intervals in
the respective indicated colour.
Flashing means, that the LED lights up very briefly in the respective col-
our and stay then clearly longer (approximately 10x longer) switched off.
Inverse flashing means the opposite. The LED lights permanently in the
respective colour and is only briefly interrupted.
Flickering means, that the LED is switched on and off in irregular inter-
vals.
3550 Wirele
