Audio Clip

(Note - WCB-100Ae does not support this function)
Audio clips are created by recording sound using the camera's microphone. Audio clips can
be played when an event occurs.
To record a new clip using the camera's microphone:
1. Enter a filename.
2. Duration - Enter the number of seconds to record.
3. Click Record.
Click Play/Stop/Delete for the audio clip if necessary.

PIR

(Note - WCB-100Ae does not support this function)
Enable PIR sensor to detect a moving infrared object such as a person in the dark. It can be
used as an intruder alarm when, for example, a thief tries to break into a house at night.
Sensitivity - is used to adjust the sensitivity of the PIR Sensor from 10 - 100%. The default
sensitivity is 50%.
- 58 -
