DOC.130918
F
P
F
P
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for KTI Networks KGS-2800
Summary of Contents for KTI Networks KGS-2800
- Page 1 DOC.130918...
-
Page 2: About This Guide
ABOUT THIS GUIDE PURPOSE This guide gives specific information on how to operate and use the management functions of the switch. AUDIENCE The guide is intended for use by network administrators who are responsible for operating and maintaining network equipment; consequently, it assumes a basic working knowledge of general switch functions, the Internet Protocol (IP), and Simple Network Management Protocol (SNMP). -
Page 3: Compliances And Safety Statements
COMPLIANCES AND SAFETY STATEMENTS FCC-CLASS A This equipment has been tested and found to comply with the limits for a Class A computing device pursuant to Subpart J of part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment. - Page 4 EMC: EN55022(2006)+A1:2007/CISPR Class A 22:2006+A1:2006 4K V CD, 8KV, AD IEC61000-4-2 (2001) 3V/m IEC61000-4-3( 2002) 1KV – (power line), 0.5KV – (signal line) IEC61000-4-4(2004) Line to Line: 1KV, Line to Earth: 2KV IEC61000-4-5 (2001) 130dBuV(3V) Level 2 IEC61000-4-6 (2003) 1A/m IEC61000-4-8 (2001) Voltage dips: >95%, 0.5period, 30%, 25periods...
- Page 5 The switch is indoor device; if it will be used in outdoor environment or connects with some outdoor device, then it must use a lightning arrester to protect the switch ARNING Self-demolition on Product is strictly prohibited. Damage caused by self-demolition will be charged for repairing fees. Do not place product at outdoor or sandstorm.
-
Page 6: Table Of Contents
Contents ABOUT THIS GUIDE......................i COMPLIANCES AND SAFETY STATEMENTS............iii INTRODUCTION........................ 1 OVERVIEW............................ 1 DESCRIPTION OF HARDWARE ................. 4 INSTALLING THE SWITCH..................7 SELECTING A SITE ........................7 ETHERNET CABLING ....................... 7 EQUIPMENT CHECKLIST ....................... 8 PACKAGE CONTENTS ......................8 MOUNTING ........................... 8 INSTALLING AN OPTIONAL SFP TRANSCEIVER........... -
Page 7: Introduction
INTRODUCTION OVERVIEW The SW24GF4TG 24-Ports GbE + 4-Port 10GbE Fiber Switch, Manufacture network next generation solutions, is a portfolio of affordable managed switches that provides reliable infrastructure for your business network. These switches deliver more intelligent features you need to improve the availability of your critical business applications, protect your sensitive information, and optimize your network bandwidth to deliver information and applications more effectively. -
Page 8: Front Of The Switches
Front of the Switches AC 100V~240V Port 1-20 GbE SFP Port 21-24 GbE RJ45/SFP Console (DB9) Power Input Fiber Connectors Fiber Connectors (Combo) Port 25-28 10GbE SFP+ Out of band 48VDC Power Input Fiber Connector Management (RJ45) Side of the Switches (FAN Location) FAN 3 FAN 2 FAN 1... - Page 9 NETWORK The switch can also be managed over the network with a web MANAGEMENT browser or Telnet application. The switch includes a built-in OPTIONS network management agent that allows it to be managed in-band using SNMP or RMON (Groups 1, 2, 3, 9) protocols. For a detailed description of the management features, refer to the User’s manual...
-
Page 10: Description Of Hardware
DESCRIPTION OF HARDWARE The switch contains 10/100/1000BASE-T RJ-45 ports. All RJ-45 1000BASE-T ports support automatic MDI/MDI-X operation, auto-negotiation PORTS and IEEE 802.3x auto-negotiation of flow control, so the optimum data rate transmission selected automatically. SW24GF4TG supports the Small Form Factor Pluggable (SFP) TRANSCEIVER transceiver slots port 1 to port 24, the port 21 to port 24 are SLOTS... - Page 11 Condition Status Light when Fiber connection with remote device is good. P1-P24 SFP Green/ Amber Blinks when any traffic is present. Link/Act/Speed The light is green when linking up 1000Mbps. The light is Amber when linking up 100Mbps. Lit Green when TP link on 10/1000Mbps speed. P21-P24 TP Lit Amber when TP link on 100Mbps speed.
- Page 12 POWER SUPPLY There are dual power inputs on the front panel of the switch for power redundancy requirement, the SW24GF4TG switch has SOCKET 100~240 VAC power socket for AC power Input and -36VDC ~ -48VDC power input via terminal block. Figure 3: Power Supply Socket AC 100~240V...
-
Page 13: Installing The Switch
INSTALLING THE SWITCH SELECTING A The Switch can be mounted in a standard 19-inch equipment SITE rack (Via Rack mount Kit). Be sure to follow the guidelines below when choosing a location. ◆ The site should: Be at the center of all the devices you want to link and ... -
Page 14: Equipment Checklist
Figure 7: RJ-45 Connections Figure 8: SFP Transceiver EQUIPMENT After unpacking this switch, please check the contents to be sure CHECKLIST you have received all the components. Then, before beginning the installation, be sure you have all other necessary installation equipment. - Page 15 Circuit Overloading: Be sure that the supply circuit to the rack assembly is not overloaded. Grounding: Rack-mounted equipment should be properly grounded. TO Rack-mount Devices: (Optional) Step1. Attach the brackets to the device using the screws provided in the Mounting Accessory.
-
Page 16: Installing An Optional Sfp Transceiver
DESKTOP OR SHELF MOUNTING: Step1. Attach the four adhesive rubber feet to the bottom of the first switch. Figure 11: Attaching the Adhesive Rubber Feet Step2. Set the device on a flat surface near an AC power source, making sure there are at least two inches of space on all sides for proper air flow. - Page 17 Figure 12: Inserting an SFP Transceiver into a Slot TO Install a SFP transceiver, do the following: Step1. Consider network and cabling requirements to select an appropriate SFP transceiver type. Step2. Insert the transceiver with the optical connector facing outward and the slot connector facing down.
-
Page 18: Connecting To Ac Power Source
CONNECTING You can plug or remove AC power cord through the AC socket from TO AC POWER AC power source. SOURCE Figure 13: Inserting the AC power cord to AC socket to power on this switch Step1. Insert the AC power cord directly into the AC socket located at the front of the switch. -
Page 19: Connecting To Dc Power Source
CONNECTING You can plug or remove DC power cable through the DC terminal TO DC POWER block from external 48VDC DC power source. SOURCE Figure 13: Inserting the DC Power cable to DC terminal block to power on this switch Step1. -
Page 20: Wiring Map For Serial Cable
WIRING MAP FOR SERIAL CABLE Table 4: Serial Cable Wiring Switch’s 8-Pin Serial Port PC’s 9-Pin DTE Port it does not support cross cable for console port... -
Page 21: Fiber Optic Sfp Devices
FIBER OPTIC An optional Gigabit SFP transceiver can be used for a backbone connection between switches, SFP DEVICES connecting to a high-speed server. Each single-mode fiber port requires 9/125 micron single-mode fiber optic cable with an LC connector at both ends. Each multimode fiber optic port requires 50/125 or 62.5/125 micron multimode fiber optic cabling with an LC connector at both ends. - Page 22 This switch uses lasers to transmit signals over fiber ARNING optic cable. The lasers are inherently eye safe in normal operation. However, user should never look directly at a transmit port when it is powered on. When selecting a fiber SFP device, considering ARNING safety, please make sure that it can function at a temperature that is not less than the recommended maximum operational...
- Page 23 new cable installations, include test parameters that are only recommendations Category 5e or for Category 5. Therefore, the first step in preparing Category 6 cable should existing Category 5 cabling for running 1000BASE-T is a be used. The Category simple test of the cable installation to be sure that it 5e and 6 specifications complies with the IEEE 802.3-2005 standards 1000 MBPS GIGABIT ETHERNET COLLISION DOMAIN...
-
Page 24: Specifications
SPECIFICATIONS PHYSICAL CHARACTERISTICS PORTS 20 10/100/1000Mbps SFP 4 GbE Combo Port TP/ (100/1000M) SFP 4 (1G/10G) SFP+ NETWORK Ports 1-20: SFP connector, INTERFACE 10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better) 100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better) 1000BASE-T: RJ-45 (100-ohm, UTP or STP cable;... -
Page 25: Management Features
THROUGHPUT 130.9 Mpps FLOW CONTROL Full Duplex: IEEE 802.3x Half Duplex: Back pressure MANAGEMENT FEATURES IN-BAND SSH/SSL, Telnet, SNMP, or HTTP MANAGEMENT SOFTWARE HTTP, TFTP in-band, Console out-of-band LOADING STANDARDS EEE 802.3 => 10Base-T Ethernet (Twisted-pair Copper) IEEE 802.3u => 100Base-TX Ethernet (Twisted-pair Copper) IEEE 802.3ab =>... -
Page 26: Compliances
COMPLIANCES EMISSIONS EN55022 (CISPR 22) Class A EN 61000-3 FCC Class A CE Mark IMMUNITY EN 61000-4-2/3/4/5/6/8/11 EN 55024...
