- Page 1 KGS-510F Ver.D Web Smart 6-Port Gigabit Ethernet Switch with Fiber Connectivity Firmware Rev1.0 up Installation Guide DOC.210429...
- Page 2 Inc. KTI Networks Inc. reserves the right to revise this documentation and to make changes in content from time to time without obligation on the part of KTI Networks Inc. to provide notification of such revision or change. For more information, contact: 15F-7, No.
- Page 3 The information contained in this document is subject to change without prior notice. © Copyright All Rights Reserved. T RADEMARKS 1 1 2 Ethernet is a registered trademark of Xerox Corp. FCC NOTICE This device complies with 47 CFR FCC Part 15, Subpart B, Class A of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including the interference that may cause undesired operation.
- Page 4 Table of Contents 1. Introduction ..........................5 1.1 Features ......................5 1.2 Product Panels ....................7 1.3 LED Indicators ..................... 7 1.4 Specifications ...................... 7 2. Installation ........................... 10 2.1 Unpacking ......................10 2.2 Safety Cautions ....................10 2.3 Mounting the Switch ..................11 2.4 Applying Power ....................
- Page 5 1. Introduction The device is a 6-port Gigabit Ethernet switch which is featured with the following communication ports in a small footprint box: Five 10/100/1000Mbps Gigabit copper ports One dual-speed SFP slot for 100Base-FX 1000Base-X Plug and Play The switch is shipped with factory default configuration which behaves like an unmanaged Gigabit switch for workgroup.
- Page 6 Provides fiber Optical Power Alarm (OPA) function Provides Automatic Laser Shutdown (ALS) function Management: - HTTP/HTTPS/SSHv2/CLI telnet/SNMP v1/v2c/v3/RMON - DHCP/DHCPv6 client, DHCP relay, DNS client, NTPv4 - IPv6 support, System Syslog, Configuration down/upload, Software upload Security: - NAS, 802.1X, MAC-based/Web/CLI authentication - IP MAC binding, TACACS+, IP source guard ...
- Page 7 1.2 Product Panels The following figure illustrates the front panel and rear panel of the switch: 1.3 LED Indicators Function POWER Power status LNK/1000M/ACT Network port 1000Mbps link status (Port 1 - Port 5) LNK/100M/ACT Network port 100Mbps link status (Port 1 - Port 5) LNK/10M/ACT Network port 10Mbps link status (Port 1 - Port 5) P6 1G...
- Page 8 Configuration Auto 1000Mbps, Full duplex Forced 100Mbps, Full duplex Transmission rate 100Mbps and 1000Mbps Network cables MMF 50/125 62.5/125, SMF 9/125 Eye safety IEC 825 compliant Switch Functions MAC Addresses Table 8K entries Forwarding & filtering Non-blocking, full wire speed Switching technology Store and forward Maximum packet length 9.6K bytes...
- Page 9 Mechanical Dimension (base) 144 x 104.5 x 26 mm Housing Enclosed metal with no fan Mounting Desktop mounting, wall mounting Environmental Operating Temperature Typical -10℃ ~ +45℃ (Main device) (* The operating temperature range of the bundled power adapter may differ from the temperature range of the main device.) Storage Temperature -40℃...
- Page 10 2. Installation 2.1 Unpacking The product package contains: The switch unit One power adapter One product CD-ROM 2.2 Safety Cautions To reduce the risk of bodily injury, electrical shock, fire and damage to the product, observe the following precautions: Do not service any product except as explained in your system documentation.
- Page 11 2.3 Mounting the Switch The switch can be mounted on a desktop or shelf or a wall. Make sure that there is proper heat dissipation from and adequate ventilation around the device. Do not place heavy objects on the device. 2.4 Applying Power Before you begin the installation, check the AC voltage of your area.
- Page 12 2.5 Reset Button The reset button is used to perform a reset to the switch. It is not used in normal cases and can be used for diagnostic purpose. If any network hanging problem is suspected, it is useful to push the button to reset the switch without turning off the power.
- Page 13 2.7 Making Fiber Connection The dual-speed SFP slot must be installed with an SFP fiber transceiver for making fiber connection. Your switch may come with one SFP transceiver pre-installed when it is shipped. Installing SFP Fiber Transceiver To install an SFP fiber transceiver into SFP slot, the steps are: 1.
- Page 14 2.8 LED Indication Function State Interpretation POWER Power status The power is supplied to the switch. The power is not supplied to the switch. LNK/1000M/ACT Port link status A 1000M link is established. (No traffic) BLINK Port link is up and there is traffic. Port link is down.
- Page 15 3. Manage the Switch The switch provides the following methods to configure and monitor the switch as follows: Making in-band management via web interface over TCP/IP network Making in-band management via telnet CLI over TCP/IP network Making in-band SNMP management over TCP/IP network 3.1 IP Address &...
- Page 16 <ipv6_router> : IPv6 router [Password] setting command is also in Security/Switch/Users command group. Security Switch Users Configuration Security Switch Users Add <user_name> <password> <privilege_level> Security Switch Users Delete <user_name> Refer to “Operation manual for telnet management”. 3.3 Configuring IP Address via Web Interface Start Web Browser Start your browser software and enter the default IP address of the switch unit to which you want to connect.
- Page 17 Select [Configuration] -> [System] -> [IP] to configure IP address Configuration Description DHCP Client Enable the DHCP client by checking this box. IP Address Provide the IP address of this switch unit. IP Mask Provide the IP mask of this switch unit. IP Router Provide the IP address of the default router for this switch unit.
- Page 18 on the network. Save Click to save the changes. Reset Click to undo any changes made locally and revert to previously saved values. Renew Click to renew DHCP. This button is only available if DHCP is enabled. 3.4 Reference Manuals for Web and Telnet Management The following operation manuals are also provided separately for Telnet and Web management: Operation manual - telnet management xxxxxx.doc Operation manual - web management xxxxx.doc...
- Page 19 3.5 Configuration for SNMP Management The switch supports SNMP v1, SNMP v2c, and SNMP v3 management. Make sure the related settings are well-configured for the switch before you start the SNMP management from an SNMP manager. Using Telnet Interface The following are available commands in telnet SNMP command group to configure SNMP-related settings: >SNMP Configuration >SNMP Mode [enable|disable]...
- Page 20 >SNMP Access Add <group_name> <security_model> <security_level> [<read_view_name>] [<write_view_name>] >SNMP Access Delete <index> >SNMP Access Lookup [<index>] Using Web Interface Select [Configuration] -> [Security] -> [SNMP]: The commands supports configuration for: Basic system configuration for SNMP v1 and SNMP v2c Basic system configuration for SNMP v1 trap, SNMP v2c trap and SNMP v3 trap Communities that permit to access to SNMPv3 agent USM (User-based Security Model) user table for SNMPv3 VACM (View-based Access Control Model) Viewer table for SNMPv3...
- Page 21 - IEEE 802.1AB LLDP MIB - IEEE 802.1X Port Access Entity (PAE) MIB - TIA 1057 LLDP Media Endpoint Discovery (MED) MIB - IEEE 802.1-Q-BRIDGE MIB - Private SFPDDM MIB (Read DDM status of the SFP ports) - Private reboot MIB (Remote boot over SNMP) - Private TFTP firmware update MIB (TFTP Firmware update over SNMP) - Private OPA function MIB (OPA configuration for the SFP ports) - Private ALS function MIB (ALS configuration for the SFP ports)
