A.1.2 Adjustable paper holder support kit
For the printer is available a swinging paper holder support kit (see fig. A.2). This accessory allows to use
bigger diameter paper rolls (max 80mm).
P C X S P T -
The kit is already assembled as shown in fig A.2.
Paper holder support kit:
1- Paper holder support
2- Paper roll pin
3- Near paper end sensor board
4- Two fastening screws of the paper holder support to the printer frame (M3x6)
5- Two disks for the paper roll containment
1
3
4
G 2 4 6 0 P a p r e h o
2
A- 3
d l r e s u p p o t r K t i a n d Q F
5
C s e n s r o
(Fig.A.2)
TG1262-2460
