Left margin
[Notes] • This command is enabled only at the beginning of the line.
• If the setting exceeds the printable area, the maximum value of the printable area is
used.
• If left margin + printing area width is greater than printable area, then printing area
width is set at maximum value.
• The horizontal and vertical motion units are specified by $1D $50. Changing the
horizontal or vertical motion unit does not affect the current left margin.
• The command $1D $50 can change the horizontal (and vertical) motion unit.
• However, the value cannot be less than the minimum horizontal movement amount
and it must be expressed in even units of the minimum horizontal movement amount.
[Default] If Font A :
If Font B :
nH = 0
[Reference] $1D $50, $1D $57
[Example]
$ 1 D $ 5 0 x y
[Name] Set horizontal and vertical motion units.
[Format] ASCII
Hex
Decimal
[Range] x = 100, 200
y = 100, 200
[Description] Sets the horizontal and vertical motion units at 1/x inches and 1/y inches, respectively.
When x is set at 0, the default setting value is used.
When y is set at 0, the default setting value is used.
[Notes] • The horizontal direction is perpendicular to the paper feed direction.
• In standard mode, the following commands use x or y, irrespective of character
rotation (upside down or 90° clockwise rotation):
• This command does not affect the previously specified values.
• The calculated result from combining this command with others is truncated to the
minimum value of the mechanical pitch or an exact multiple of that value.
[Default] x = 200, y = 200
[Reference] $1B $20, $1B 24, $1B $5C, $1B $33, $1B $4A, $1D $4C, $1D $57
[Example]
$ 1 D $ 5 7 n L n H
[Name] Set printing area width.
[Format] ASCII
Hex
Decimal
0 ≤ nL, nH ≤ 255
[Range]
[Description] Sets the printing area width to the area specified by nL and nH.
TG1260/2460
Width of print area
nL = nH = 0
nL =14
GS P
1D 50
29 80
Commands using x : $1B $20, $1B $24, $1B $5C, $1D $4C, $1D $57.
Commands using y : $1B $33, $1B $4A.
GS W
1D 57
29 87
2. PRINTER FUNCTIONS
x y
x y
x y
nL nH
nL nH
nL nH
2-26
