A.1.1.2 Power supply for TG1260
The figure below illustrates the power supply provided by Custom to be used for printer operation.
(Fig.A.1.2)
L
N
PE
-V
-V
+V
+V
PPSPS-070-12V
Input specification
Specifiche di uscita
Condizioni ambientali
Protection devices: Shortcircuit, overload and overvoltage.
TG1260-2460
APPENDIX A - ACCESSORIES AND SPARE PARTS
Switching power supply 12V÷070W
Input voltage
Current
Inpout frequency
Output voltage
Output current Min. Max.
Efficency Min
Operating temperature
Humidity
Storage temperature/
Humidity
85V ÷ 264
0A ÷ 1,8A
47 Hz ÷ 63 Hz
12V
0A ÷ 6,0A
80%
0°C ÷ 70°C
20% ÷ 85% Rh (w/o condensation)
-10°C ÷ 75°C/
10% ÷ 95% Rh (w/o condensation)
A- 2
(Tab.A.1.2)
