To clean, do not use harsh chemical solvents; the use of a soft, alcohol-moistened
cloth is recommended.
To change the paper roll in the printer, proceed as follows:
1) Position the paper roll (1), so that it rotates in the direction shown in fig.1.6;
2) Insert the end of the paper roll in the print mechanism (2)and wait until the roll loads automatically;
3) Remove the ticket from the mouth paper output;
WARNING
Before inserting the paper, ensure that it is cut evenly.

1.4.2 Notes for installation and using the printer in the upside down position

To install the printer in the upside down position proceed as follows :
Release the spring
from this side
TG1260/2460
1. INSTALLATION AND OPERATION
1- 6
(Fig.1.8)
(Fig.1.9)
