Autotest - Custom Engineering TG1260 series User Manual

• Speed/Quality: Normal
• Offline (1) : Disabled D
• Print density: Normal
Notes: The parameters indicates with a
(1) NOTE: Using this parameter, it is possible to select whether the Busy signal is activated
when the printer is both in Off Line status and the buffer is full, or only if the reception
buffer is full.
(2)
NOTE: These parameters are shown only for the USB interface models.
The settings made are saved on the EEPROM (non volatile memory).
During the setup routine the printer prints out the setup report and will remain in standby until another key is
pressed or characters are received through the printer communication port. After this, each time the "PRINT"
key is pressed, the parameter is modified and its current value is printed. Once the required value has been
obtained, press the "FEED" key to proceed to the next parameter, and so on. Once all the parameters have
been run through, the printing of a message signals the end of the setting procedure.

1.3 AUTOTEST

To run the autotest, press the "FEED" key while switching on the printer. During the running of the autotest, the
character fonts and logos stored inside the printer are printed.
TG1260/2460
1. INSTALLATION AND OPERATION
D , Low.
, Enabled.
D , Dark, Very Dark, Light, Very Light.
D
symbol are the default values.
* PRINTER SETUP *
PROGRAM MEMORY..................OK
PRINTER BUFFER......................OK
CUTTER......................................OK
HEAD VOLTAGE............ [V]
HEAD TEMPERATURE [°C]
Printer Emul.
Baud Rate
Data length
Parity
Handshaking
Autofeed
USB Address
USB Monitor
Panel key
Print Mode
Chars / line
Speed/Quality
Offline
Print Density
[PRINT] key to enter setup
[FEED] key to skip setup
= 24,00
= 32,5
: ESC/POS (TM)
: 9600 bps
: 8 bits/chr
: None
: Xon/Xoff
: CR disabled
: 0
: Disabled
: Enabled
: Normal
: A=32/B=42 col
: Normal
: Disabled
: Normal
1- 4
(Fig.1.5)
