Custom Engineering TG1260 series User Manual page 4

B. TG1260/TG2460-x-P
(2) The x suffix indicates the following models :
- TG1260/TG2460-U-P: USB interface and plastic front panel.
- TG1260/TG2460-S-P: RS232 serial interface and plastic front panel.
1- Printing mechanism
2- "Print" key
3- "Feed" key
4- Power supply connector
5- USB interface connector
6- Printer frame
7- Plastic front panel
8- Paper output
9- Status Led
C. TG1260/TG2460-x-M
(3)
The x suffix indicates the following models :
- TG1260/TG2460-U-M: USB interface and metal front panel without autocutter model.
- TG1260/TG2460-S-M: RS232 serial interface and metal front panel without autocutter model.
1- Printing mechanism
2- "Print" key
3- "Feed" key
4- Power supply connector
5- USB interface connector
6- Printer frame
7- Metal front panel
8- Paper output
9- Status Led
TG1260/2460
