CHAPTER 2. ANATOMY AND FUNCTIONS 12
Loop volume can also be controlled via expression pedal (see Expres-
sion Pedal Functions, page 39)
2.4

Jacks

DC Power

Use only the 18-Volt, 300mA, negative-tip power supply that came
with your Pigtronix Infinity Looper. Using the wrong power supply is
likely to result in a damaged pedal.
In 1
Looper input 1. This is normally the input to use, unless you are using
both inputs for stereo or two instruments.
In 2
Looper input 2. Use this input for the second input of a stereo signal,
or a second instrument using Input Split. When nothing is connected
to Input 2, the signal from Input 1 is automatically passed to Input 2.
Out 1
Main pass-through/loop output, uses a standard (TS) 1/4 instrument
cable. Amp, mixer, or DI goes here.
