CHAPTER 2. ANATOMY AND FUNCTIONS
2.5
LEDs
Loop LEDs
The Loop 1 and Loop 2 footswitch LEDs share the same color coding,
and light pattern (for colorblind users).
Both Loop 1 and Loop 2 footswitch LEDs are accompanied by a red
square Arm LED that indicates which loop is currently armed.
When an external MIDI Clock is used, the Arm LED for the currently
selected Loop will blink at the received tempo.
Stop LED
The Stop LED will glow red when loop audio is stopped. When
stopped, if no audio is recorded, the Stop LED will not be lit.
Clip LED
This red LED between the Loop Volume knobs will indicate when
the input signal is reaching the maximum headroom of the Infinity's
recording engine and begins to trigger the analog limiter stages. If
the Clip LED is lighting up solid red, reduce the output level of your
instrument until the Clip LED is just beginning to light up at the peaks
in your audio signal.
Green
Red
Playback
Recording
Solid
Slow Flicker
Orange
Overdub
Quick Flicker
15
