CHAPTER 3. INFINITY RULES
3.11

Input Split

The Input Split function is intended for isolating Loop 1 to audio
channel 1 and Loop 2 to audio channel 2. This is helpful if you want
to loop multiple instruments on isolated, yet synchronized loops.
When nothing is plugged into Input 2, then the audio from Input 1
becomes the source for Input 2 (as well as Input 1) and the Input
Split function allows you to record separate loops for the left and right
output channels.
3.12

Presets

The Infinity Looper allows you to store and recall up to 50 presets,
which consist of audio that you've either recorded by playing through
the Infinity, or audio you've loaded onto the pedal from your computer
using the app. Each preset includes a Loop 1, as well as a Loop 2 if
you've recorded a second loop.
The 50 presets are organized into five banks of 10.

Loading

To Load a preset, simply turn the Preset knob until you arrive at the
desired preset, then press the knob to select.
The Sync Multi Bar Graph indicates the currently selected bank the
top (x1) corresponds to Bank 1 and the bottom (x6) corresponds to
Bank 5 and the Multi-Segment Digit displays the preset number within
the chosen bank.
22
