Accessories common to all products:
Product references
AC0102-02
AC0103-00
AC0201-01
AC0201-02
AC0201-03
AC0501-01
This manual covers all versions of the product.
1.3

Target group

This guide is aimed at installers.
1.4

General operating principle

The WebdynRF platform is the new range of Webdyn concentrators dedicated to
wireless networks. Gathering data from meters or sensors and checking I/Os are
basic functionalities for the WebdynRF gateway. The services targeted by the
WebdynRF gateway are remote meter reading, and buildings energy management.
WebdynRF – Installation Manual - Version 1.0
Versions
12V external power supply unit
24V DIN rail-mounted power supply
Remote dual-band GPRS antenna with 5m
of cable
Remote dual-band GPRS antenna with
20m of cable
Remote dual-band GPRS antenna with
10m of cable
IP67 box, circuit breaker, 24V DC power
supply, UPS unit and 12V lead batteries
WEBDYN
WebdynRF
Installation Manual
5
