Remarks concerning this manual

This guide describes the assembly, installation and commissioning of the device.
Please ensure these instructions are always available.
For management instructions for the data exchanged by the gateway with the remote
server, refer to the operating manual for the WebdynRF gateway (cf. ME-
WebdynRF_FR.pdf).
1.1

Scope

This technical description is valid for Wavenis WebdynRF gateways from hardware
version 1 and software version 2.4.0. onwards.
1.2

Product versions

Depending on the type of GSM modem and radio card, there are several product
versions:
Wavenis radio card:
Product references
WG0606-A01
WG0606-A02
WG0606-A03
WG0606-A04
WG0606-A11
WG0606-A12
WG0606-A13
WG0606-A14
WG0606-A21
WG0606-A22
Wireless M-Bus radio card:
Product references
WG0607-A01
WG0607-A02
WG0607-A11
WG0607-A12
RFID radio card:
Product reference
WG0608-A01
WebdynRF – Installation Manual - Version 1.0
Versions
2G modem – 868 MHz/25 mW Wavenis
3G modem – 868 MHz/25 mW Wavenis
2G modem – 868 MHz/500 mW Wavenis
3G modem – 868 MHz/500 mW Wavenis
2G modem – 915 MHz/25 mW Wavenis
3G modem – 915 MHz/25 mW Wavenis
2G modem – 915 MHz/500 mW Wavenis
3G modem – 915 MHz/500 mW Wavenis
2G modem – 433 MHz/10 mW Wavenis
3G modem – 433 MHz/10 mW Wavenis
Versions
WebdynRF-WirelessMbus-868 MHz-2G
WebdynRF-WirelessMbus-868 MHz-3G
WebdynRF-WirelessMbus-169 MHz-2G
WebdynRF-WirelessMbus-169 MHz-3G
Versions
2G modem - RFID
