Follower schedule:
A "Follower" schedule will be produced after the end of each occurrence of the
reference schedule. The Parent schedule cannot be a "Follower" schedule.
This type, for example, enables the uploading of data to be triggered after completion
of a data gathering operation envisaged.
Example:
You want to gather data from all the Wavenis modules once a day at midnight and
download the data just after that. You can configure a "Daily" schedule for the data
gathering and a "Follower" schedule for the first schedule for uploading data.
Examples:
Need Type
Every Weekly
Tuesday at
15:00:00
Every 2nd Monthly
day of the
month at
00:00:00
Every day at Daily
14:00:00
Every hour Weekly
from 8H00 to
18H00 every
Tuesday
Every 2 hours Yearly
from 8H00 to
20H00 on 31
December
8.6

Configuration of the Wavenis radio network

Wavenis product versions
There are two ways of implementing the Wavenis radio network:
• If you already know the full Wavenis mapping, you can configure the modules
manually one by one by using the Wavenis table on the onboard Web
interface.
• If you wish to build your Wavenis network by using the gateway as a Waveport
and the Wavenet Monitor configuration tool, you can directly import the
configuration file from this Coronis tool.
The gateway supports the following Wavenis modules:
• Waveflow (1, 2 and 4 inputs)
• Dallas Wavetherm (1 and 2 inputs), PT100 (1 input) and PT1000 (1 input)
• Wavesense 4-20mA (1 input) and 0-5V (1 input)
• Wavelog (2 and 4 inputs)
WebdynRF – Installation Manual - Version 1.0
Time Day of
Week
2
15:00:00
00:00:00
14:00:00
08:00:00 2
Day of Date & Time
Month
2
2012-12-
31T08:00:00
WEBDYN
WebdynRF
Installation Manual
Interval Count
0 1
0 1
0 1
3600 11
7200 7
35
