Configuration of the modem connection

8.2.1
Parameters Description
Off: The SIM card's PIN code must be deactivated.
Manual: The SIM card's PIN code must be entered in the PIN Code
PIN Mode
box.
Automatic: Not implemented.
The SIM card's PIN code to be filled in if Manual is selected in PIN
PIN Code
Mode.
GPRS call number. The default number *99***1# is valid in the
Call Number
majority of cases.
APN Name of the APN of your mobile operator.
Login
Your mobile operator's APN user name.
Password Your mobile operator's APN password.
OnDemand: The gateway establishes the connection only when it has
to communicate with the remote server. It cuts it off when the data
transfer is completed after a timeframe that can be configured in
Disconnect delay.
AlwaysOn: Not implemented.
AlwaysOff: This mode is to be used in the case of connection with the
Mode
remote server via Ethernet. This connection is done via modem, but if
a valid SIM card is inserted, the gateway may receive incoming SMSs
or calls and transmit SMSs.
Off: The modem is always off. This mode is to be used in the case of
connection with the remote server via Ethernet without the possibility
of receiving calls or SMSs or sending SMSs.
Disconnect Value of the wait delay in OnDemand between the end of data
delay exchanges and the end of the connection.
Caller ID List of the telephone numbers permitted for incoming SMSs and calls.
