Installing the SAS/SATA controller

To install the SAS/SATA controller, complete the following steps.
1. Touch the static-protective package that contains the SAS/SATA controller to
2. Position the SAS/SATA controller over the connector and the plastic standoff;
3. Connect the signal cable to the SAS/SATA controller.
4. Install and lock the side cover (see "Installing the side cover" on page 40).
5. Reconnect the external cables and power cords; then, turn on the attached
any unpainted surface on the outside of the server; then, remove the SAS/SATA
controller from the package.
then, press the SAS/SATA controller firmly into the connector and onto the
plastic standoff.
devices and turn on the server.
SAS controller
Chapter 4. Removing and replacing server components
85
