v Hard disk drive capacities affect how you create arrays. The drives in an array
v If you use an integrated SAS/SATA controller with RAID capabilities to configure
v If you install a different type of RAID controller, see the documentation that

Starting the LSI Configuration Utility program

To start the LSI Configuration Utility program, complete the following steps:
1. Turn on the server.
2. When the prompt <<< Press <CTRL><C> to start LSI Configuration Utility
3. To select a controller (channel) from the list of adapters, use the arrow keys and
4. To change the settings of the selected items, follow the instructions on the
When you have finished changing settings, press Esc to exit from the program;
select Save to save the settings that you have changed.

Formatting a hard disk drive

Low-level formatting removes all data from the hard disk. If there is data on the disk
that you want to save, back up the hard disk before you perform this procedure.
Note: Before you format a hard disk, make sure that the disk is not part of a
mirrored pair.
To format a drive, complete the following steps:
1. From the list of adapters, select the controller (channel) for the drive that you
2. Select SAS Topology and press Enter.
3. Select Direct Attach Devices and press Enter.
4. To highlight the drive that you want to format, use the Up Arrow and Down
5. To start the low-level formatting operation, select Format and press Enter.
Creating a RAID array of hard disk drives
To create a RAID array of hard disk drives, complete the following steps:
1. From the list of adapters, select the controller (channel) for the drives that you
2. Select RAID Properties.
3. Select the type of array that you want to create.
4. Use the arrow keys to highlight the first drive in the pair; then, press the Minus
24
System x3200 Types 4362 and 4363: Problem Determination and Service Guide
can have different capacities, but the RAID controller treats them as if they all
have the capacity of the smallest hard disk drive.
a RAID 1 (mirrored) array after you have installed the operating system, you will
lose access to any data or applications that were previously stored on the
secondary drive of the mirrored pair.
comes with the controller for information about viewing and changing settings for
attached devices.
>>> is displayed, press Ctrl+C. If you have set an administrator password, you
are prompted to type the password.
press Enter.
screen. If you select Raid Properties, SAS Topology, or Advanced Adapter
Properties additional screens are displayed.
want to format and press Enter.
Arrow keys. To scroll left and right, use the Left Arrow and Right Arrow keys or
the End key. Press Alt+D.
want to mirror.
(-) or Plus (+) key to change the mirror value to Primary.
