Technical Specifications

INPUTS:
OUTPUTS:
MAX. DATA RATE:
COMPLIANCE WITH HDMI
STANDARD:
CONTROLS:
INDICATOR LEDs:
POWER CONSUMPTION:
OPERATING TEMPERATURE:
STORAGE TEMPERATURE:
HUMIDITY:
DIMENSIONS:
WEIGHT:
INCLUDED ACCESSORIES:
OPTIONAL:
Specifications are subject to change without notice at
VM-114H4C - Technical Specifications
1 HDMI Connector
1 TP on an RJ-45 Connector
4 TP on RJ-45 Connectors
4.95Gbps (1.65Gbps bandwidth per graphic channel)
(DGKat)
Supports HDMI and HDCP
Input select button, EDID select button, panel lock button,
RS-232, local and remote IR controls
IR communication, Power, IN 1 HDMI, IN 2 CAT5,
OUTPUT 1, 2, 3 and 4
12V DC, 2A
0° to +40°C (32° to 104°F)
-40° to +70°C (-40° to 158°F)
10% to 90%, RHL non-condensing
21.5cm x 16.3cm x 4.4cm (8.5in x 6.4in x 1.7in) W, D, H
0.9kg (1.98lbs) approx.
Power supply, RC-IR3 infrared remote control transmitter
RK-1 19" rack adapter
http://www.kramerelectronics.com
