Kramer VM-114H2C User Manual

2 input 1:4 hdmi da/2x cat5 outputs
Hide thumbs Also See for VM-114H2C:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Kramer Electronics, Ltd.

USER MANUAL

Model:
VM-114H2C
2 Input 1:4 HDMI DA/2x CAT5 Outputs

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VM-114H2C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kramer VM-114H2C

Summary of Contents for Kramer VM-114H2C

  • Page 1: User Manual

    Kramer Electronics, Ltd. USER MANUAL Model: VM-114H2C 2 Input 1:4 HDMI DA/2x CAT5 Outputs...

  • Page 2: Table Of Contents

    Connecting to the VM-114H2C via RS-232 RS-232 and IR Control and Pass-through 5.4.1 RS-232 Control and Pass-through Using the VM-114H2C 5.4.2 Local IR Control and IR Pass-through Using the VM-114H2C Wiring the Twisted Pair RJ-45 Connectors Technical Specifications Default Communication Parameters Default EDID...
  • Page 3 Contents Tables Table 1: VM-114H2C Front Panel Features Table 2: VM-114H2C Rear Panel Features Table 3: Technical Specifications of the VM-114H2C Table 4: Default Communication Parameters Table 5: Protocol Definitions Table 6: Instruction Codes for Protocol 2000 KRAMER: SIMPLE CREATIVE TECHNOLOGY...

  • Page 4: Introduction

    Our 1,000-plus different models now appear in 11 groups that are clearly defined by function. Congratulations on purchasing your Kramer Desktop VM-114H2C 2 Input 1:4 HDMI DA/2x CAT5 Outputs. The VM-114H2C is ideal for: • Home theater, presentation and multimedia applications •...

  • Page 5: Quick Start

    Getting Started Quick Start This quick start chart summarizes the basic setup and operation steps of the VM-114H2C. KRAMER: SIMPLE CREATIVE TECHNOLOGY...

  • Page 6: Overview

    Overview Overview The high quality VM-114H2C 2 Input 1:4 HDMI DA/2x CAT5 Outputs is a switcher/distribution amplifier for HDMI and TP (Twisted Pair) signals. It reclocks and equalizes one of two selectable input signals and distributes it to two HDMI and two TP outputs.

  • Page 7: About Hdmi

    NTSC or PAL Using Shielded Twisted Pair Cable Kramer engineers have developed special twisted pair cables to best match our digital twisted pair products; the Kramer: BC-DGKat524 (CAT 5 24 AWG), the Kramer BC-DGKat623 (CAT 6 23 AWG cable), and the Kramer BC-DGKat7a23 (CAT 7a 23 AWG cable).

  • Page 8: About The Power Connect™ Feature

    Overview The VM-114H2C supports a range of up to 90m (295ft) at 1080i/SXGA, or up to 30m (98ft) at 1080p/UXGA on shielded BCP-DGKat524 cable; 90m (295ft) at 1080i or up to 70m (230ft) at 1080p/UXGA on shielded BCP-DGKat623 cable. You can daisy-chain up to six devices with the maximum overall distance between the first and last devices being cumulative and limited by the cable type used.

  • Page 9: Defining The Vm-114H2C

    Defining the VM-114H2C Defining the VM-114H2C Figure 1 Table 1 define the front panel of the VM-114H2C. Figure 1: VM-114H2C Front Panel Table 1: VM-114H2C Front Panel Features Feature Function IR Remote Control Sensor Sensor for the remote control IR transmitter...

  • Page 10: Figure 2: Vm-114H2C Rear Panel

    Defining the VM-114H2C Figure 2 Table 2 define the rear panel of the VM-114H2C. Figure 2: VM-114H2C Rear Panel Table 2: VM-114H2C Rear Panel Features Feature Function RS-232 9-pin D-sub (F) Connect to a PC or remote controller Connector 12V DC Power Connector...

  • Page 11: Using The Vm-114H2C

    1. Connect the HDMI source (for example, a DVD player) to the IN 1 (HDMI) connector. 1 Switch off the power on each device before connecting it to your VM-114H2C. After connecting your VM-114H2C, switch on its power and then switch on the power on each device...

  • Page 12: Acquiring The Edid

    6. Optional—Connect a PC via RS-232 to the RS-232 port on the VM-114H2C (see Section 5.3). 7. Connect the power adapter to the power socket on the VM-114H2C and to the mains electricity (not shown in Figure 8. Optional—Press the EDID READ button to acquire or change the EDID...

  • Page 13: 5.2.1 Disabling/Enabling Deep Color Support

    To connect to the VM-114H2C via RS-232: • Connect the RS-232 9-pin D-sub rear panel port on the VM-114H2C unit via a 9-wire straight cable (only pin 2 to pin 2, pin 3 to pin 3, and pin 5 to...

  • Page 14: 5.4.1 Rs-232 Control And Pass-Through Using The Vm-114H2C

    Figure 4: VM-114H2C RS-232 Control and Pass-through 5.4.2 Local IR Control and IR Pass-through Using the VM-114H2C The VM-114H2C provides an IR sensor and a 3.5mm mini jack for connecting a remote IR emitter or sensor. When the VM-114H2C is connected to suitable...

  • Page 15: Figure 5: Vm-114H2C Ir Control And Pass-Through Example One

    A DVD player is connected to the TP-573 transmitter via an IR emitter. An LCD display is connected to the TP-574 receiver via an IR emitter. Both the TP-573 and the TP-574 are connected to the VM-114H2C via TP cabling.

  • Page 16: Figure 6: Vm-114H2C Ir Control And Pass-Through Example Two

    An IR sensor is connected to the TP-573 transmitter. An LCD display is connected to the TP-574 receiver via an IR emitter. Both the TP-573 and the TP-574 are connected to the VM-114H2C via TP cabling. To control the LCD display, point the LCD display remote control either at the TP-573 IR sensor or at the VM-114H2C IR sensor.

  • Page 17: Figure 7: Vm-114H2C Ir Control And Pass-Through Example Three

    The first DVD player (player 1) is connected to the TP-573 transmitter via an IR emitter. The second DVD player (player 2) is connected to the VM-114H2C via an IR emitter. An IR sensor is connected to the TP-574 receiver.

  • Page 18: Wiring The Twisted Pair Rj-45 Connectors

    Wiring the Twisted Pair RJ-45 Connectors Wiring the Twisted Pair RJ-45 Connectors When using STP cable, connect/solder the cable shield to the RJ-45 connector shield. Figure 8 defines the TP pinout using a straight pin-to-pin cable with RJ-45 connectors. Note, that the cable Ground shielding must be connected/soldered to the connector shield.

  • Page 19: Technical Specifications

    ACCESSORIES: Power supply, RC-IR3 infrared remote control transmitter OPTIONS: HDMI/HDMI male-to-male cables, RK-1 19” rack adapter Default Communication Parameters Table 4 lists the default communication parameters for the VM-114H2C. Table 4: Default Communication Parameters RS-232 Protocol 2000 Baud Rate: 9600...

  • Page 20: Default Edid

    Default EDID Default EDID The factory default EDID is listed below. Monitor Model name....VM114H2C Manufacturer..... KRM Plug and Play ID..KRM0114 Serial number.... 505-707455010 Manufacture date..2009, ISO week 10 ------------------------- EDID revision.... 1.3 Input signal type..Digital Color bit depth..Undefined Display type.....

  • Page 21: Kramer Protocol 2000

    (implement) the command, and the addressed machine will reply. For a single machine controlled via the serial port, always set M4…M0 = 1, and make sure that the machine itself is configured as MACHINE NUMBER = 1. KRAMER: SIMPLE CREATIVE TECHNOLOGY...

  • Page 22: Table 6: Instruction Codes For Protocol 2000

    Kramer Protocol 2000 Table 6: Instruction Codes for Protocol 2000 Note: All values in the table are decimal, unless otherwise stated. INSTRUCTION DEFINITION FOR SPECIFIC INSTRUCTION NOTE DESCRIPTION INPUT OUTPUT SWITCH VIDEO Set equal to video input Set equal to video output which is...
  • Page 24 For the latest information on our products and a list of Kramer distributors visit www.kramerelectronics.com where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
