Summary of Contents for Kramer VM-114H4C
-
Page 1: User Manual
Kramer Electronics, Ltd. USER MANUAL Model: VM-114H4C 2 Input 1:4 HDMI DA/4x CAT5 Outputs... -
Page 2: Table Of Contents
Connecting to the VM-114H4C via RS-232 RS-232 and IR Control and Pass-through 5.4.1 RS-232 Control and Pass-through Using the VM-114H4C 5.4.2 Local IR Control and IR Pass-through Using the VM-114H4C Technical Specifications Default Communication Parameters Default EDID Kramer Protocol 2000... -
Page 3: Introduction
Our 1,000-plus different models now appear in 11 groups that are clearly defined by function. Congratulations on purchasing your Kramer Desktop VM-114H4C, which is ideal for: • Home theater, presentation and multimedia applications •... -
Page 4: Quick Start
Getting Started Quick Start This quick start chart summarizes the basic setup and operation steps of the VM-114H4C. KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 5: Overview
Overview Overview The high quality VM-114H4C is a switcher/distribution amplifier for HDMI and TP (Twisted Pair) signals. It reclocks and equalizes one of two selectable input signals and distributes it to four TP outputs. In particular, the VM-114H4C: • Supports up to 1.65Gbps bandwidth per graphic channel (DGKat) •... -
Page 6: About Hdmi
NTSC or PAL Using Shielded Twisted Pair Cable Kramer engineers have developed special twisted pair cables to best match our digital twisted pair products; the Kramer: BC-DGKat524 (CAT 5 24 AWG), the Kramer BC-DGKat623 (CAT 6 23 AWG cable), and the Kramer BC-DGKat7a23 (CAT 7a 23 AWG cable). -
Page 7: About The Power Connect™ Feature
Overview The VM-114H4C supports a range of up to 90m (295ft) at 1080i/SXGA or up to 30m (98ft) at 1080p/UXGA on shielded BCP-DGKat524 cable; 90m (295ft) at 1080i or up to 70m (230ft) at 1080p/UXGA on shielded BCP-DGKat623 cable. About the Power Connect™ Feature The Power Connect™... -
Page 8: Defining The Vm-114H4C
Defining the VM-114H4C Defining the VM-114H4C Figure 1 Table 1 define the front panel the VM-114H4C. Figure 1: VM-114H4C Front Panel Table 1: VM-114H4C Front Panel Features Feature Function IR Remote Control Sensor Sensor for the remote control IR transmitter... -
Page 9: Using The Vm-114H4C
VM-114H2C or a VM-1114H4C) to the IN 2 (CAT5) connector. 1 Switch OFF the power on each device before connecting it to your VM-114H4C. After connecting your VM-114H4C, switch on its power and then switch on the power on each device... -
Page 10: Acquiring The Edid
PT-572+ Line Receiver , the VM-114H or the VM-114H2C). 4. (Optional) Connect the front panel remote IR 3.5mm mini jack to the remote IR sensor. 5. (Optional) Connect a PC via RS-232 to the RS-232 port on the VM-114H4C (see Section 5.3). -
Page 11: Disabling/Enabling Deep Color Support
Using the VM-114H4C You can acquire the EDID from: • One output (the relevant output LED flashes) • The default EDID (all output LEDs flash) • Up to four connected outputs using the Auto-mix Mode (all output LEDs light) When pressing the EDID SELECT button briefly, the OUTPUT LEDs indicate the source from which the EDID is acquired as follows: •... -
Page 12: Connecting To The Vm-114H4C Via Rs-232
Section 5.2. Connecting to the VM-114H4C via RS-232 You can connect to the VM-114H4C via an RS-232 connection using, for example, a PC. Note that a null-modem adapter/connection is not required. To connect to the VM-114H4C via RS-232: • Connect the RS-232 9-pin D-sub rear panel port on the product unit via a... -
Page 13: Rs-232 And Ir Control And Pass-Through
Figure 4: VM-114H4C RS-232 Control and Pass-through 5.4.2 Local IR Control and IR Pass-through Using the VM-114H4C The VM-114H4C provides an IR sensor and a 3.5mm mini jack for connecting a remote IR emitter or sensor. When the VM-114H4C is connected to suitable... -
Page 14: Figure 5: Vm-114H4C Ir Control And Pass-Through Example One
A DVD player is connected to the TP-573 transmitter via an IR emitter. An LCD display is connected to the TP-574 receiver via an IR emitter. Both the TP-573 and the TP-574 are connected to the VM-114H4C via TP cabling. -
Page 15: Figure 6: Vm-114H4C Ir Control And Pass-Through Example Two
An IR sensor is connected to the TP-573 transmitter. An LCD display is connected to the TP-574 receiver via an IR emitter. Both the TP-573 and the TP-574 are connected to the VM-114H4C via TP cabling. To control the LCD display, point the LCD display remote control either at the TP-573 IR sensor or at the VM-114H4C IR sensor. -
Page 16: Figure 7: Vm-114H4C Ir Control And Pass-Through Example Three
The first DVD player (player 1) is connected to the TP-573 transmitter via an IR emitter. The second DVD player (player 2) is connected to the VM-114H4C via an IR emitter. An IR sensor is connected to the TP-574 receiver. -
Page 17: Technical Specifications
Power supply, RC-IR3 infrared remote control transmitter OPTIONS: HDMI/HDMI male to male cables, RK-1 19” rack adapter Default Communication Parameters Table 4 lists the default communication parameters for the VM-114H4C. Table 4: Default Communication Parameters RS-232 Protocol 2000 Baud Rate:... -
Page 18: Default Edid
1024 x 768p at 75Hz - VESA 1280 x 1024p at 75Hz - VESA 1280 x 1024p at 60Hz - VESA STD 1600 x 1200p at 60Hz - VESA STD 1152 x 864p at 75Hz - VESA ST KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 19: Kramer Protocol 2000
Kramer Protocol 2000 Kramer Protocol 2000 This RS-232 communication protocol uses four bytes of information as defined below. The default data rate is 9600 baud, with no parity, 8 data bits and 1 stop bit. Table 5: Protocol Definitions DESTI-... -
Page 20: Table 6: Instruction Codes For Protocol 2000
NOTE 14 - The number of inputs and outputs refers to the specific machine which is being addressed, not to the system. For example, if six 16X16 matrices are configured to make a 48X32 system (48 inputs, 32 outputs), the reply to the HEX code 82 (ie. request the number of outputs) would be HEX codes ie. 16 outputs KRAMER: SIMPLE CREATIVE TECHNOLOGY... - Page 21 1. Any product which is not distributed by us or which is not purchased from an authorized Kramer dealer. If you are uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site www.kramerelectronics.com.
- Page 22 For the latest information on our products and a list of Kramer distributors visit www.kramerelectronics.com where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
